Field Setting from Outdoor Unit PCB ESIE15-13C
84 Field Setting
53 Free cooling kkkhkhk
X = OFF, Y = OFF (factory
set)
khhhhhk
X = 0, Y = 5 khhhhkh
X = 2, Y = 5 khhhhkk
X = 4, Y = 5 khhhkhh
X = 0, Y = 10 khhhkhk
X = 2, Y = 10 khhhkkh
X = 4, Y = 10 khhhkkk
54
Weather depending
control TeS Lower limit
value A
kkkhkkh
9°C (factory set) khhhhhk
11°C khhhhkh
13°C khhhhkk
15°C khhhkhh
57
Weather depending
control TeS Lower limit
value B
kkkkhhk
2°C (factory set) khhhhhk
4°C khhhhkh
6°C khhhhkk
8°C khhhkhh
58
Weather depending
control TeS Lower limit
value C
kkkkhkh
14°C (factory set) khhhhhk
17°C khhhhkh
20°C khhhhkk
23°C khhhkhh
59
Weather depending
control TeS Lower limit
value D
kkkkhkk
23°C (factory set) khhhhhk
27°C khhhhkh
31°C khhhhkk
35°C khhhkhh
60
Weather depending
control TcS Upper limit
value E
kkkkkhh
47°C (factory set) khhhhhk
48°C khhhhkh
49°C khhhhkk
50°C khhhkhh
61
Weather depending
control TcS Upper limit
value F
kkkkkhk
43°C (factory set) khhhhhk
44°C khhhhkh
45°C khhhhkk
46°C khhhkhh
62
Weather depending
control TcS Upper limit
value G
kkkkkkh
2°C (factory set) khhhhhk
5°C khhhhkh
8°C khhhhkk
11°C khhhkhh
63
W
eather depending
control TcS Upper limit
value H
kkkkkkk
15°C (factory set) khhhhhk
18°C khhhhkh
21°C khhhhkk
24°C khhhkhh
The figures in the columns under "No." represent the number of times to push the SET (BS2) button.
h: OFF k: ON
No.
Display of setting items Display of setting conditions
Setting items
LED display
Setting condition
LED Display
H1P H2P H3P H4P H5P H6P H7P H1P H2P H3P H4P H5P H6P H7P
