Daikin RZQG71L9V1B [47/215] Switchable fan speed
![Daikin RZQG71L9V1B [47/215] Switchable fan speed](/views2/1769719/page47/bg2f.png)
ESIE15-13C Function Details
Function and Control 33
In dry operation
Note: *1: The thermistor to detect room temperature is as follows according to field setting.
· Factory setting: Indoor unit suction air thermistor
· When set to remote controller thermistor: Indoor air thermistor in the remote controller
3.1.3 Switchable Fan Speed
The setting airflow rate when the thermo. is turned on and off by operation mode is as shown
below. The airflow rate when the thermo. is turned off can be changed in field setting. The table
below shows the factory setting.
3.1.4 Swing Pattern Selection
Swing flaps operate as shown in the table below.
3.1.5 Drain Pump Control (Only for FCQG & FCQHG)
Cooling / Dry Operation
Normally drain pump ON (Thermostat ON/OFF)
Tro > 24ºC
16ºC ≥ Tro
24ºC ≥ Tro > 16ºC
ΔT < -2.5ºC
Δ > -1ºC
Thermostat OFF
Dry operation
ΔT < -2ºC
Δ > -1ºC
Thermostat OFF
Dry operation
Tr < 13ºC
Tr > 15ºC
Thermostat OFF
Dry operation
Fan
Cooling
Thermostat ON Set
Thermostat OFF Set
Program Dry
Thermostat ON L
Thermostat OFF OFF
Heating
Thermostat ON Set
Thermostat OFF LL
Fan Set
Stop OFF
Fan
Cooling
Flap Set
Thermostat ON Set
Thermostat OFF Set
Swing Set
Thermostat ON Swing
Thermostat OFF Swing
Program Dry
Flap Set
Thermostat ON Set
Thermostat OFF Set
Swing Set
Thermostat ON Swing
Thermostat OFF Swing
Heating
Flap Set
Thermostat ON Set
Thermostat OFF Horizontal
Swing Set
Thermostat ON Swing
Thermostat OFF Horizontal
Fan Flap Set Set
Stop Swing Set Swing
