ESIE15-13C Field Setting from Outdoor Unit PCB
Field Setting 83
3.2.3 Setting Mode 2
In this mode, settings for the following items can be made.
Press the MODE (BS1) button for 5
seconds and set to “Setting mode 2”.
Press the SET (BS2) button and set the
LED display to a setting item (∗1).
↓
Press the RETURN (BS3) button and
decide the item.
<Selection of setting items>
<Selection of setting conditions>
Press the SET (BS2) button and set to
the setting condition you want.
↓
Press the RETURN (BS3) button and
decide the condition.
Press the RETURN (BS3) button and
set to the initial status of “Setting mode
2”.
∗ If you become unsure of how to proceed, push the MODE (BS1) button and return to setting mode 1.
h: OFF k: ON
No.
Display of setting items Display of setting conditions
Setting items
LED display
Setting condition
LED Display
H1P H2P H3P H4P H5P H6P H7P H1P H2P H3P H4P H5P H6P H7P
3 Demand 2 operation bck h h h h bck bck
30% Demand khhhkhh
40% Demand (factory set) khhhhkh
50% Demand khhhhhk
7
Reduced airflow (set to
low noise level 1)
bck h h h bck bck bck
OFF khhhhhh
ON khhhhhk
11 TeS Lower limit value bck h h bck h bck bck
0°C khhhhhk
2°C (factory set) khhhhkh
4°C khhhhkk
6°C khhhkhh
28
Refrigerant recovery
mode
khkkkhh
OFF (factory setting) khhhhhk
ON khhhhkh
33 TeS Lower limit value kkhhhhk
0°C (factory set) khhhhhk
6°C khhhhkh
9°C khhhhkk
11°C khhhkhh
13°C khhhkhk
15°C khhhkkh
17°C khhhkkk
Weather depending control
in cooling
khhkhhh
34 TcS Upper limit value kkhhhkh
60°C khhhhhk
50°C khhhhkh
47°C khhhhkk
45°C khhhkhh
43°C khhhkhk
Weather depending control
in heating
khhhkkh
