ESIE15-13C Service Mode
Remote Controller 23
[In the case of individual setting per indoor unit, current
settings are displayed. And, SECOND CODE NO. “-”
means no function.]
Highlight SECOND CODE NO. of the FIRST CODE NO.
to be changed, and select desired “SECOND CODE NO.”
by using the
(Up/Down) button. Multiple identical
mode number settings are available.
In the case of individual
setting per indoor unit
