Chapter 1: Product Introduction
1-2
If any of the above items is damaged or missing, contact your retailer.
1.1 System package contents
Check your system package for the following items.
Model Name
RS700A-E9-RS4V2 RS700A-E9-RS12V2
Chassis
ASUS R12F 1U Rackmount Chassis ASUS R12F 1U Rackmount Chassis
Motherboard
ASUS KNPP-D32-R Server Board ASUS KNPP-D32-R Server Board
Component
1 x 800W 80PLUS Platinum Power Supply
1 x 3.5-inch Storage Device Backplane
4 x 3.5-inch Storage Device Trays or
Dummy Trays
1 x Front Panel Board
2 x Riser Card
8 x System Fans (40 mm x 40 mm x 56
mm)
1 x 800W 80PLUS Platinum Power Supply
1 x 2.5-inch Storage Device Backplane
12 x 2.5-inch Storage Device Trays or
Dummy Trays
1 x Front Panel Board
2 x Riser Card
8 x System Fans (40 mm x 40 mm x 56
mm)
1 x PCIE-NVME2-OCuLink card
Accessories
1 x AMD EPYC™ Support DVD
1 x Bag of Screws
2 x CPU Heatsink
2 x AC Power Cable
1 x AMD EPYC™ Support DVD
1 x Bag of Screws
2 x CPU Heatsink
2 x AC Power Cable
Optional
Items
1 x Redundant 800W 80PLUS Platinum
Power Supply (Second PSU)
1 x Friction Rail Kit
1 x Slim type DVD-RW
1 x Redundant 800W 80PLUS Platinum
Power Supply (Second PSU)
1 x Friction Rail Kit
2 x OCuLink to OCuLink cables for NVMe
1 x PCIE-NVME2-OCuLink card with two
cables
1 x PCIE-NVME4-OCuLink card with four
cables
