Asus RS700A-E9-RS4V2 [18/192] Rear panel features

Chapter 1: Product Introduction

1-8

*This port is for ASUS ASMB9-iKVM only.

1.5 Rear panel features

The rear panel includes the expansion slots, system power sockets, and rear fans. The

middle part includes the I/O shield with openings for the rear panel connectors on the

motherboard.

Expansion slot

Message LED

LAN port 1

LAN port 2

Q-Code LED

VGA port

Redundant Power supply and

Power cord connector

Management LAN port 1*

Expansion slots

USB ports

Power button

Storage device LED

Location LED
