5-51
ASUS RS700A-E9 Series V2
BMC network configuration
The sub-items in this configuration allow you to configure the BMC network parameters.
IPV4
DM_LAN1
Configuration Address source [Previous State]
This item allows you to configure LAN channel parameters statistically or dynamically
(by BIOS or BMC). Unspecified option will not modify any BMC network parameters
during BIOS phase.
Configuration options: [Previous State] [Static] [DynamicBmcDhcp]
Shared LAN
Configuration Address source [Previous State]
This item allows you to configure LAN channel parameters statistically or dynamically
(by BIOS or BMC). Unspecified option will not modify any BMC network parameters
during BIOS phase.
Configuration options: [Previous State] [Static] [DynamicBmcDhcp]
IPV6
DM_LAN1
IPV6 Support [Enabled]
Allows you to enable or disable LAN1 IPV6 Support.
Configuration options: [Disabled] [Enabled]
The following item appears only when IPV6 Support is set to [Enabled].
Configuration Address source [Previous State]
This item allows you to configure LAN channel parameters statistically or dynamically
(by BIOS or BMC). Unspecified option will not modify any BMC network parameters
during BIOS phase.
Configuration options: [Previous State] [Static] [DynamicBmcDhcp]
Shared LAN
IPV6 Support [Enabled]
Allows you to enable or disable LAN2 IPV6 Support.
Configuration options: [Disabled] [Enabled]
The following items appear only when IPV6 Support is set to [Enabled].
Configuration Address source [Previous State]
This item allows you to configure LAN channel parameters statistically or dynamically
(by BIOS or BMC). Unspecified option will not modify any BMC network parameters
during BIOS phase.
Configuration options: [Previous State] [Static] [DynamicBmcDhcp]
