ASUS RS700A-E9 Series V2
1-5
Model Name RS700A-E9-RS4V2 RS700A-E9-RS12V2
Networking LAN
1 x Dual Port Intel I350-AM2 Gigabit LAN controller
1 x Management Port
Optional OCP Adapter: Up to 100Gb/s Ethernet / InfiniBand Adapter
Graphic VGA
Aspeed AST2500 64MB
Auxiliary Storage Device Bay
(Floppy / Optical Drive)
N/A
I/O ports, Switches, and
LEDs
Front I/O Ports:
2 x USB 3.1 Gen 1 ports
1 x VGA port
Rear I/O Ports:
2 x USB 3.1 Gen 1 ports
1 x VGA port
2 x RJ-45 GbE LAN ports
1 x RJ-45 Mgmt LAN port
Rear Switch/LED:
1 x Power switch
1 x Q-Code/Port 80 LED
1 x Message LED
1 x Storage device LED
1 x Location LED
Front Switch/LED:
1 x Power switch/LED
1 x Location switch/LED
1 x Message LED
1 x Storage device LED
LAN 1-4 LEDs
* LAN 3-4 for Mezzanine card use
Rear I/O Ports:
2 x USB 3.1 Gen 1 ports
1 x VGA port
2 x RJ-45 GbE LAN ports
1 x RJ-45 Mgmt LAN port
Rear Switch/LED:
1 x Power switch
1 x Q-Code/Port 80 LED
1 x Message LED
1 x Storage device LED
1 x Location LED
Front Switch/LED:
1 x Power switch/LED
1 x Location LED
1 x Message LED
1 x Storage device LED
LAN 1-2 LED
Security Options
TPM 2.0 Header
Management
Solution
Out of Band
Remote
Hardware
On-Board ASMB9-iKVM for KVM-over-IP
Software
ASUS Control Center (Classic)
OS Support
Please find the latest OS support from http://www.asus.com
(continued on the next page)
