ASUS RS500-E8 V2 Series
5-45
Smbios Event Log Standard Settings
Log System Boot Event [Disabled]
Allowsyoutochooseoptionstoenable/disableloggingofSystembootevent.Conguration
options:[Enabled][Disabled]
MECI [1]
Multiple Event Count Increment (MECI). The number of occurrences of a duplicate event
that must pass before the multiple-event counter associated with the log entry is updated,
speciedasanumericvalueintherange1to255.
METW [60]
Multiple Event Time Windows (METW). The number of minutes which must pass between
duplicate log entries which utilize a multiple-event counter. The value ranges from 0 to 99
minutes.
Custom Option
Log OEM Codes [Enabled]
Enable or disable the logging of EFI Status Codes as OEM Codes (if not already converted to
legacy).Congurationoptions:[Disabled][Enabled]
Convert OEM Codes [Disabled]
Enable or disable the converting of EFI Status Codes to Standard Smbios Types (Not all may
be translated).
Congurationoptions:[Disabled][Enabled]
5.7.2 View Smbios Event Log
Press <Enter> to view all smbios event logs.
