ASUS RS500-E8 V2 Series
1-5
*Specifications are subject to change without notice.
Model Name
RS500-E8-PS4 V2 RS500-E8-RS4 V2
Onboard I/O Connectors
1 x TPM Header
1 x 24-pin SSI power connector + 8-pin SSI 12V + 8-pin SSI 12V
1 x External Serial Port (RS500-E8-PS4 V2)
3 x RJ-45 ports (1 for ASMB8-iKVM)
2 x USB 3.0 port (rear I/O)
2 x USB 2.0 port (front I/O)
1 x VGA port
1 x Chassis intruder
1 x PS/2 keyboard/mouse combo port
OS Support
Windows
®
Server 2012
Windows
®
8 64-bit
Windows
®
Server 2008 Enterprise SP2 64-bit
Windows
®
Server 2008 Enterprise R2 SP1 64-bit
RedHat
®
Enterprise Linux AS 5.8/6.3 U8 64-bit
Centos 5.8/6.2/6.3 64-bit
* Subject to change without any notice.
Management
Solution
Software
ASWM Enterprise
Out of Band
Remote
Management
ASMB8-iKVM for KVM-over-Internet
Dimension (HH x WW x DD)
615 mm x 444 mm x 44 mm
Net Weight Kg
(CPU, DRAM & HDD not
included)
16 Kg
Power Supply
Single 600W 80PLUS Gold
Power Supply
Single 650W 80PLUS
Platinum Power Supply
1+1 Redundant 770W 80PLUS
Gold Power Supply
Power Rating
100-127/200-240VAC, 9A/5A,
50-60Hz, Class I
100-127/200-240Vac, 10A/5A,
50-60Hz, Class I
Environment
Operating temperature:
10
°
C – 35
°
C
Non operation temperature:
-40
°
C – 70
°
C
Non operation humidity:
20% – 90% (Non condensing)
