Chapter 4: Motherboard Information
4-2
4.1 Motherboard layout
Layout contents
Jumpers
Page
1. Clear RTC RAM (3-pin CLRTC1) 4-4
2. VGA controller setting (3-pin VGA_SW1)
4-5
3. LAN controller setting (3-pin LAN_SW1, LAN_SW2) 4-5
4. MErmwareforcerecoverysetting(3-pinME_RCVR1) 4-6
5. DDR4thermaleventsetting(3-pinDIMMTRIP1) 4-6
6. RAIDcongurationutilityselection(3-pinRAID_SEL1) 4-7
7. BMC Setting (3-pin BMC_EN1) 4-7
