Daikin 2MXS50H2V1B [15/32] Capacity tables
![Daikin 2MXS40H2V1B [15/32] Capacity tables](/views2/1771726/page15/bgf.png)
• Split - Sky Air
®
• Outdoor Unit
13
• Outdoor Unit • Multi model application • MXS-H
4 Capacity tables
4 - 3 Cooling Capacity Tables
2MXS50H2V1B
3D063432A
+
Cooling (50Hz 230V)
Combination
(Capacity)
Outdoor air
temp.
°CDB
Indoor air temperature: °CWB
14°C 16°C 18°C 19°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.0
10.0 2.91 0.42 3.03 0.43 3.15 0.44 3.21 0.44 3.38 0.45 3.50 0.47
12.0 2.86 0.43 2.98 0.44 3.10 0.44 3.16 0.45 3.34 0.46 3.46 0.47
15.0 2.78 0.44 2.90 0.45 3.02 0.46 3.08 0.46 3.26 0.48 3.38 0.49
18.0 2.71 0.46 2.83 0.46 2.95 0.47 3.01 0.48 3.19 0.49 3.31 0.50
20.0 2.66 0.47 2.78 0.48 2.90 0.48 2.96 0.49 3.14 0.50 3.26 0.51
22.0 2.62 0.48 2.74 0.49 2.85 0.50 2.91 0.50 3.09 0.51 3.21 0.52
25.0 2.54 0.49 2.66 0.50 2.78 0.51 2.84 0.52 3.02 0.53 3.14 0.54
28.0 2.47 0.51 2.59 0.52 2.71 0.53 2.77 0.54 2.95 0.55 3.07 0.56
32.0 2.37 0.54 2.49 0.55 2.61 0.56
2.67 0.56
2.85 0.57 2.97 0.58
35.0 2.30 0.56 2.42 0.57 2.54 0.58 2.60 0.58 2.78 0.59 2.90 0.60
40.0 2.18 0.59 2.30 0.60 2.42 0.61
2.48 0.62
2.66 0.63 2.78 0.64
43.0 2.11 0.62 2.23 0.62 2.35 0.63 2.41 0.64 2.59 0.65 2.71 0.66
46.0 2.03 0.64 2.15 0.65 2.27 0.66 2.33 0.66 2.51 0.68 2.63 0.69
2.5
10.0 3.46 0.58 3.61 0.59 3.75 0.60 3.82 0.61 4.04 0.63 4.18 0.64
12.0 3.41 0.59 3.55 0.60 3.69 0.61 3.76 0.62 3.98 0.64 4.12 0.65
15.0 3.32 0.61 3.46 0.62 3.61 0.63 3.68 0.64 3.89 0.66 4.03 0.67
18.0 3.23 0.63 3.38 0.64 3.52 0.65 3.59 0.66 3.81 0.68 3.95 0.69
20.0 3.18 0.64 3.32 0.66 3.46 0.67 3.53 0.67 3.75 0.69 3.89 0.71
22.0 3.12 0.66 3.26 0.67 3.40 0.68 3.48 0.69 3.69 0.71 3.83 0.72
25.0 3.03 0.68 3.17 0.69 3.32 0.71 3.39 0.71 3.60 0.73 3.75 0.75
28.0 2.95 0.71 3.09 0.72 3.23 0.73 3.30 0.74 3.52 0.76 3.66 0.77
32.0 2.83 0.74 2.97 0.75 3.12 0.77
3.19 0.77
3.40 0.79 3.54 0.81
35.0 2.74 0.77 2.89 0.78 3.03 0.79 3.10 0.80 3.31 0.82 3.46 0.83
40.0 2.60 0.82 2.74 0.83 2.88 0.84
2.96 0.85
3.17 0.87 3.31 0.88
43.0 2.51 0.85 2.65 0.86 2.80 0.87 2.87 0.88 3.08 0.90 3.23 0.91
46.0 2.43 0.88 2.57 0.89 2.71 0.91 2.78 0.91 3.00 0.93 3.14 0.95
3.5
10.0 4.00 0.77 4.65 0.91 4.84 0.93 4.93 0.94 5.21 0.97 5.39 0.99
12.0 4.00 0.80 4.58 0.93 4.76 0.95 4.86 0.96 5.13 0.99 5.32 1.01
15.0 4.00 0.86 4.47 0.96 4.65 0.98 4.75 0.99 5.02 1.02 5.21 1.04
18.0 4.00 0.92 4.36 0.99 4.54 1.01 4.63 1.02 4.91 1.05 5.09 1.07
20.0 4.00 0.96 4.28 1.02 4.47 1.04 4.56 1.05 4.84 1.08 5.02 1.09
22.0 4.00 1.01 4.21 1.04 4.39 1.06 4.48 1.07 4.76 1.10 4.94 1.12
25.0 3.91 1.06 4.10 1.08 4.28 1.10 4.37 1.11 4.65 1.14 4.83 1.15
28.0 3.80 1.09 3.98 1.11 4.17 1.13 4.26 1.14 4.54 1.17 4.72 1.19
32.0 3.65 1.15 3.84 1.17 4.02 1.19
4.11 1.20
4.39 1.23 4.57 1.25
35.0 3.54 1.19 3.72 1.21 3.91 1.23 4.00 1.24 4.28 1.27 4.46 1.29
40.0 3.35 1.27 3.54 1.29 3.72 1.31
3.81 1.32
4.09 1.35 4.27 1.37
43.0 3.24 1.32 3.43 1.34 3.61 1.36 3.70 1.37 3.98 1.40 4.16 1.42
46.0 3.13 1.37 3.31 1.39 3.50 1.41 3.59 1.42 3.87 1.45 4.05 1.47
Combination
(Capacity)
Outdoor air
temp.
°CDB
Indoor air temperature: °CWB
14°C 16°C 18°C 19°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
4.2
10.0 3.50 0.74 4.30 0.95 5.16 1.19 5.61 1.33 6.12 1.45 6.34 1.48
12.0 3.50 0.78 4.30 0.99 5.16 1.25 5.61 1.39 6.03 1.48 6.25 1.51
15.0 3.50 0.82 4.30 1.06 5.16 1.33 5.58 1.48 5.90 1.52 6.12 1.55
18.0 3.50 0.88 4.30 1.13 5.16 1.43 5.44 1.53 5.77 1.57 5.99 1.60
20.0 3.50 0.92 4.30 1.18 5.16 1.50 5.36 1.56 5.68 1.60 5.90 1.63
22.0 3.50 0.96 4.30 1.24 5.16 1.58 5.27 1.59 5.59 1.64 5.81 1.67
25.0 3.50 1.03 4.30 1.33 5.03 1.63 5.14 1.65 5.46 1.69 5.68 1.72
28.0 3.50 1.11 4.30 1.44 4.90 1.69 5.01 1.71 5.33 1.75 5.55 1.78
32.0 3.50 1.23 4.30 1.61 4.72 1.77
4.83 1.79
5.16 1.83 5.37 1.86
35.0 3.50 1.33 4.30 1.75 4.59 1.84 4.70 1.85 5.02 1.90 5.24 1.93
40.0 3.50 1.54 4.16 1.92 4.37 1.95
4.48 1.97
4.81 2.01 5.02 2.01
43.0 3.50 1.69 4.03 1.99 4.24 2.02 4.35 2.04 4.67 2.08 4.89 2.11
46.0 3.50 1.86 3.89 2.07 4.11 2.10 4.22 2.11 4.54 2.16 4.76 2.19
5.0
10.0 3.92 0.85 4.82 1.10 5.78 1.40 6.29 1.57 6.64 1.62 6.87 1.65
12.0 3.92 0.89 4.82 1.15 5.78 1.46 6.19 1.60 6.54 1.65 6.78 1.69
15.0 3.92 0.95 4.82 1.23 5.78 1.57 6.05 1.65 6.40 1.70 6.64 1.74
18.0 3.92 1.01 4.82 1.31 5.78 1.69 5.91 1.71 6.26 1.76 6.49 1.79
20.0 3.92 1.06 4.82 1.38 5.69 1.73 5.81 1.75 6.16 1.79 6.40 1.83
22.0 3.92 1.11 4.82 1.45 5.60 1.77 5.72 1.78 6.07 1.83 6.30 1.87
25.0 3.92 1.19 4.82 1.56 5.46 1.83 5.57 1.85 5.93 1.89 6.16 1.93
28.0 3.92 1.29 4.82 1.69 5.31 1.89 5.43 1.91 5.78 1.96 6.02 1.99
32.0 3.92 1.43 4.82 1.90 5.12 1.98
5.24 2.00
5.59 2.05 5.83 2.08
35.0 3.92 1.56 4.75 2.02 4.98 2.06 5.10 2.07 5.45 2.12 5.69 2.15
40.0 3.92 1.81 4.51 2.15 4.75 2.18
4.86 2.20
5.21 2.25 5.42 2.25
43.0 3.92 1.99 4.37 2.23 4.59 2.25 4.70 2.25 5.01 2.25 5.21 2.25
46.0 3.92 2.21 4.19 2.25 4.41 2.25 4.51 2.25 4.82 2.25 5.01 2.25
2.0 + 2.0
10.0 5.59 0.98 5.82 1.00 6.05 1.02 6.16 1.03 6.51 1.07 6.74 1.11
12.0 5.50 1.00 5.73 1.02 5.96 1.04 6.07 1.05 6.42 1.09 6.65 1.11
15.0 5.36 1.03 5.59 1.05 5.82 1.08 5.93 1.09 6.28 1.12 6.51 1.14
18.0 5.22 1.07 5.45 1.09 5.68 1.11 5.79 1.12 6.14 1.15 6.37 1.18
20.0 5.12 1.09 5.35 1.11 5.58 1.14 5.70 1.15 6.04 1.18 6.27 1.20
22.0 5.03 1.12 5.26 1.14 5.49 1.16 5.61 1.17 5.95 1.20 6.18 1.23
25.0 4.89 1.16 5.12 1.18 5.35 1.20 5.47 1.21 5.81 1.24 6.04 1.27
28.0 4.75 1.20 4.98 1.22 5.21 1.24 5.33 1.25 5.67 1.29 5.90 1.31
32.0 4.56 1.26 4.79 1.28 5.02 1.30
5.14 1.31
5.49 1.35 5.72 1.37
35.0 4.42 1.31 4.65 1.33 4.88 1.35 5.00 1.36 5.35 1.39 5.58 1.42
40.0 4.19 1.39 4.42 1.41 4.65 1.43
4.77 1.44
5.11 1.48 5.34 1.50
43.0 4.05 1.44 4.28 1.47 4.51 1.49 4.63 1.50 4.97 1.53 5.20 1.55
46.0 3.91 1.50 4.14 1.52 4.37 1.54 4.49 1.55 4.83 1.59 5.06 1.61
NOTES SYMBOLS
1 Capacities are based on the following conditions.
Corresponding refrigerant piping length: 5.0m
Level difference: 0m
2 The bold line is indicated the standard condition.
3 The above is the value for connecting with the following indoor units.
2.0, 2.5, 3.5, 4.2, 5.0 kW class; wall mounted ATXS-G, FTXS-J (NW-S2)series.
TC: Total capacity (kW)
PI: Power input (kW)
