RKS+FBQ35-60B
Cooling capacity 230V [50Hz]
Outdoor
Indoor Outdoor temperature (°C)
EWB EDB 20 25 30 32 35 40
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
35
14.0 20.0 3.2 2.4 0.91 3.1 2.3 1.01 3.0 2.2 1.12 2.9 2.2 1.13 2.8 2.1 1.16 2.7 2.0 1.25
16.0 22.0 3.4 2.6 0.92 3.3 2.5 1.03 3.2 2.4 1.14 3.1 2.4 1.15 3.1 2.3 1.18 2.9 2.2 1.28
18.0 25.0 3.7 2.8 0.94 3.6 2.7 1.05 3.4 2.6 1.16 3.4 2.5 1.17 3.3 2.5 1.20 3.2 2.4 1.30
19.0 27.0 3.8 2.9 0.95 3.7 2.8 1.06 3.6 2.7 1.17 3.5 2.6 1.18 3.4 2.6 1.21 3.3 2.4 1.31
22.0 30.0 4.2 3.2 0.97 4.1 3.0 1.09 3.9 2.9 1.20 3.9 2.9 1.22 3.8 2.8 1.25 3.6 2.7 1.35
24.0 32.0 4.5 3.3 0.99 4.3 3.2 1.11 4.2 3.1 1.22 4.1 3.1 1.24 4.0 3.0 1.27 3.8 2.9 1.37
50
14.0 20.0 5.1 3.6 1.57 4.9 3.5 1.67 4.8 3.4 1.76 4.7 3.4 1.80 4.6 3.4 1.86 4.5 3.3 1.95
16.0 22.0 5.2 3.6 1.60 5.1 3.5 1.69 4.9 3.5 1.79 4.9 3.4 1.83 4.8 3.4 1.88 4.6 3.3 1.98
18.0 25.0 5.4 3.6 1.62 5.2 3.6 1.72 5.1 3.5 1.81 5.0 3.5 1.85 4.9 3.4 1.91 4.8 3.4 2.00
19.0 27.0 5.5 3.7 1.64 5.3 3.6 1.73 5.2 3.5 1.83 5.1 3.5 1.87 5.0 3.5 1.92 4.9 3.4 2.02
22.0 30.0 5.7 3.7 1.68 5.5 3.6 1.77 5.4 3.6 1.87 5.3 3.5 1.90 5.2 3.5 1.96 5.1 3.4 2.06
24.0 32.0 5.8 3.7 1.70 5.7 3.7 1.80 5.5 3.6 1.89 5.5 3.6 1.93 5.4 3.5 1.99 5.2 3.5 2.08
60
14.0 20.0 5.8 4.6 1.84 5.6 4.6 1.94 5.5 4.5 2.03 5.4 4.5 2.07 5.3 4.4 2.13 5.2 4.3 2.22
16.0 22.0 5.9 4.7 1.87 5.8 4.6 1.96 5.6 4.5 2.06 5.6 4.5 2.10 5.5 4.5 2.15 5.3 4.4 2.25
18.0 25.0 6.1 4.7 1.89 5.9 4.6 1.99 5.8 4.6 2.08 5.7 4.5 2.12 5.6 4.5 2.18 5.5 4.4 2.27
19.0 27.0 6.2 4.7 1.91 6.0 4.6 2.00 5.9 4.6 2.10 5.8 4.5 2.13 5.7 4.5 2.19 5.6 4.4 2.29
22.0 30.0 6.4 4.8 1.95 6.2 4.7 2.04 6.1 4.6 2.14 6.0 4;6 2.17 5.9 4.6 2.23 5.8 4.5 2.33
24.0 32.0 6.5 4.8 1.97 6.4 4.7 2.07 6.2 4.7 2.16 6.2 4.6 2.20 6.1 4.6 2.26 5.9 4.5 2.35
3TW25112-1
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
TC: Total capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
NOTES
1. Ratings shown are net capacities which include a deduction for indoor fan
motor heat
2. Shows nominal cooling capacities and power input
3. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.29 x 60 x AFR (m
3
/min) x (1-BF) x (DB-EDB)/860
AddSHC*toSHC.
4. Direct interpolation is permissible.
Do not extrapolate.
5. Capacities are based on the following conditions:
Corresponding refrigerant piping length: 7.5 m
Level difference: 0 m
6. Air flow rate and BF are tabulated below.
Model FCQ
35
AFR 11.5
BF 0.15
50
AFR 14
BF 0.15
60
AFR 19
BF 0.11
•
Pair Application • R-410A • RKS25-35-50-60-71BVMB
3
Capacity tables
3
14
• Split - Sky Air • Outdoor Units
