Si12-308 Instruction
System Configuration 143
2.10 INTELLIGENT EYE Operation
FTK(X)E 25/35 B
INTELLIGENT EYE Operation
“INTELLIGENT EYE” is the infrared sensor which
detects the human movement.
■
To start INTELLIGENT
EYE operation
1. Press “SENSOR button”.
■
To cancel the
INTELLIGENT EYE
operation
2. Press “SENSOR button” again.
[EX.]
C
TEMP
ON/OFF
POWERFUL
HOME LEAVE
MODE
TIMER
FAN
SWING
SILENT
SENSOR
ON
CANCEL
OFF
1, 2
When somebody in the room
• Normal operation
When nobody in the room
• 20 min. after, start
energy saving
operation
.
Somebody back in the room
• Back to normal operation.
