Specifications Si12-308
32 Specifications
Floor / Ceiling Suspended Dual Type
230V, 50Hz
Model FLKS25BVMB FLKS35BVMB
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color Almond White Almond White
Air Flow Rates
m³/min
(cfm)
H 7.6 (268) 8.6 (304)
M 6.8 (240) 7.6 (268)
L 6.0 (212) 6.6 (233)
SL 5.2 (184) 5.6 (198)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 34 34
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.34 0.36
Power Consumption (Rated) W 74 78
Power Factor % 94.6 94.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200 490×1,050×200
Packaged Dimension mm 1,100×566×280 1,100×566×280
Weight kg 16 16
Gross Weight kg 22 22
Operation
Sound
H/M/L/SL dBA 37/34/31/28 38/35/32/29
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model FLKS50BVMB FLKS60BVMB
Rated Capacity 5.0W Class 5.7kW Class
Front Panel Color Almond White Almond White
Air Flow Rates
m³/min
(cfm)
H 11.4 (402) 12.0 (424)
M 10.0 (353) 10.7 (378)
L 8.5 (300) 9.3 (328)
SL 7.5 (265) 8.3 (293)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 34 34
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.45 0.45
Power Consumption (Rated) W 96 98
Power Factor % 92.8 94.7
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200 490×1,050×200
Packaged Dimension mm 1,100×566×280 1,100×566×280
Weight kg 17 17
Gross Weight kg 24 24
Operation
Sound
H/M/L/SL dBA 47/43/39/36 48/45/41/39
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
18.0
φ
18.0
