Si12-308 Piping Diagrams
Appendix 267
FLK(X)25 / 35 / 50 / 60AVMA
FIELD PIPING
FIELD PIPING
(
CuT
)
(
6.4CuT
)
INDOOR UNIT
SIROCCO FAN
(
CuT
)
REFRIGERANT FLOW
(
CuT
)
M
FAN MOTOR
COOLING
HEATING
HEAT EXCHANGER
THERMISTOR
ON HEAT
EXCH.
FLX35-
FLK35-
FLX50-
FLK50-
FLK25-
FLK60-
FLX25-
FLX60-
12.7
12.7
15.9
9.5
4D034013
12.7
12.7
9.5
9.5
9.5
6.4
6.4
9.5
