Si12-308 Instruction
System Configuration 145
FTK(X)D 50/60/71 B
INTELLIGENT EYE Operation
“INTELLIGENT EYE” is the infrared sensor which
detects the human movement.
■
To start INTELLIGENT
EYE operation
1. Press “SENSOR button”.
■
To cancel the
INTELLIGENT EYE
operation
2. Press “SENSOR button” again.
[EX.]
C
TEMP
ON/OFF
POWERFUL
HOME LEAVE
MODE
TIMER
FAN
SILENT
ON
CANCEL
OFF
SWING
1, 2
SENSOR
When somebody in the room
• Normal operation
When nobody in the room
•
20 min. after, start
energy saving
operation
.
Somebody back in the room
•
Back to normal operation.
