Si12-308 Specifications
Specifications 47
Wall Mounted Type
230V, 50Hz
Model
FTXS25BVMB FTXS35BVMB
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.4 (261) 7.5 (265) 7.4 (261) 7.5 (265)
M 5.8 (205) 6.3 (222) 5.9 (208) 6.3 (222)
L 4.1 (145) 5.0 (177) 4.4 (155) 5.2 (184)
SL 3.6 (127) 4.5 (159) 3.8 (134) 4.6 (162)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimension mm 834×325×258 834×325×258
Weight kg 8 8
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/33/28/25 39/33/26/23 39/34/29/26
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model
FTXS50BVMB FTXS60BVMB
Cooling Heating Cooling Heating
Rated Capacity 5.0kW Class 6.0kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 11.4 (402) 12.6 (445) 16.2 (572) 17.4 (614)
M 9.7 (342) 10.8 (381) 13.6 (480) 15.1 (533)
L 8.0 (282) 8.9 (314) 11.4 (402) 12.7 (448)
SL 7.1 (251) 7.7 (272) 10.2 (360) 11.4 (402)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.20 0.18 0.20
Power Consumption (Rated) W 40 45 40 45
Power Factor % 96.6 97.8 96.6 97.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×795×238 290×1,050×238
Packaged Dimension mm 840×338×280 1,147×366×337
Weight kg 9 12
Gross Weight kg 13 17
Operation
Sound
H/M/L/SL dBA 44/40/35/32 42/38/33/30 45/41/36/33 44/40/35/32
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
18.0
φ
18.0
