Si12-308 Specifications
Specifications 45
Wall Mounted Type
60Hz 220V
Model
FTXE25BVMT FTXE35BVMT
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.8 (275) 8.1 (286) 7.8 (275) 8.1 (286)
M 6.4 (226) 6.6 (233) 6.6 (233) 6.7 (237)
L 5.0 (177) 5.0 (177) 5.0 (177) 5.2 (184)
SL 4.4 (155) 4.4 (155) 4.4 (155) 4.4 (155)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.21 0.21 0.21 0.21
Power Consumption (Rated) W 45 45 45 45
Power Factor % 97.4 97.4 97.4 97.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimension mm 834×325×258 834×325×258
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 38/34/30/27 38/34/30/27 39/36/32/29 39/35/31/28
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model
FTXD50BVMT FTXD60BVMT
Cooling Heating Cooling Heating
Rated Capacity 5.0kW Class 6.0kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 15.4 (544) 16.1 (568) 16.2 (572) 17.1 (604)
M 12.9 (455) 13.7 (484) 13.6 (480) 14.8 (522)
L 10.8 (381) 11.5 (406) 11.4 (402) 12.5 (441)
SL 9.6 (339) 10.2 (360) 10.2 (360) 10.9 (385)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.19 0.19 0.21 0.21
Power Consumption (Rated) W 40 40 45 45
Power Factor % 95.7 95.7 97.4 97.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimension mm 1,147×366×337 1,147×366×337
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 44/40/35/32 42/38/33/30 45/41/36/33 44/40/35/32
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
