Si06-305 Specifications
Specifications 5
1.2 Heat Pump
230V, 50Hz
Notes:
MAX. interunit piping length: 20m
MAX. interunit height difference: 15m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Model
Indoor Units FVXS25BVMB FVXS35BVMB
Outdoor Units
RXS25BVMB RXS35BVMB
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.5 (1.0~3.0) 3.4 (1.0~5.0) 3.5 (1.0~3.7) 4.5 (1.0~5.0)
Btu/h 8,550 (3,400~10,250) 11,600 (3,400~17,050) 11,950 (3,400~12,600) 15,350 (3,400~17,050)
kcal/h 2,150 (860~2,580) 2,920 (860~4,300) 3,010 (860~3,180) 3,870 (860~4,300)
Moisture Removal L/h 1.2 — 1.9 —
Running Current (Rated) A 3.7 4.3 5.5 6.0
Power Consumption Rated
(Min.~Max.)
W 700 (240~925) 840 (240~1,430) 1,160 (240~1,300) 1,285 (240~1,830)
Power Factor (Min.~Max.) % 82.3 84.9 91.7 93.1
COP W/W 3.57 4.05 3.02 3.50
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
20.0
φ
20.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FVXS25BVMB FVXS35BVMB
Front Panel Color Almond White Almond White
Air Flow Rate
m³/min
(cfm)
H 8.1 (286) 9.2 (325) 8.3 (293) 9.2 (325)
M 6.2 (219) 7.0 (247) 6.3 (222) 7.1 (251)
L 4.3 (152) 4.8 (169) 4.3 (152) 5.0 (177)
SL 3.4 (120) 3.5 (124) 3.4 (120) 3.6 (127)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output
Upper/Lower
W 14/14 14/14
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Upward Right, Left, Horizontal and Upward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.14 0.14 0.14 0.14
Power Consumption (Rated) W 32 32 32 32
Power Factor % 99.4 99.4 99.4 99.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 600×650×195 600×650×195
Packaged Dimensions (W×D×H) mm 770×294×714 770×294×714
Weight kg 13 13
Gross Weight kg 19 19
Operation
Sound
H/M/L/SL dBA 38 / 32 / 26 / 23 38 / 32 / 26 / 23 39 / 33 / 27 / 24 39 / 34 / 29 / 26
Sound Power H dBA 54 — 55 —
Outdoor Unit RXS25BVMB RXS35BVMB
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23GXD#A 1YC23GXD#A
Motor Output W 600 600
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.4 0.4
Refrigerant
Model R410A R410A
Charge kg 0.96 1.06
Air Flow Rate
m³/min (H/L) 25.3/17.0 22.8/15.3 25.3/17.0 22.8/15.3
cfm (H/L) 893/600 805/540 893/600 805/540
Fan
Type Propeller Propeller
Motor Output W 19 19
Running Current (Rated) A 3.56 4.16 5.36 5.86
Power Consumption (Rated) W 668 808 1,128 1,253
Power Factor % 81.6 84.4 91.5 93.0
Starting Current A 4.3 6.0
Dimensions (H×W×D) mm 560×695×265 560×695×265
Packaged Dimensions (W×D×H) mm 797×310×599 797×310×599
Weight kg 37 37
Gross Weight kg 40 40
Operation
Sound
H/L dBA 46 / 43 47 / 44 47 / 44 48 / 45
Sound Power H dBA 59 — 60 —
Drawing No. 3D040172A 3D040173A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
