8 | Configuration
Installer reference guide
110
ERGA04~08DAV3(A) + EHVH04+08SU18+23DA6V7
Daikin Altherma 3 R F
4P618956-1 – 2020.03
1 Go to [B]: User profile.
User profile
B
2 Enter the applicable pin code for the user permission level. —
▪ Browse through the list of digits and change the selected digit.
▪ Move the cursor from left to right.
▪ Confirm the pin code and proceed.
Installer pin code
The Installer pin code is 5678. Additional menu items and installer settings are
now available.
5678
Installer
Advanced user pin code
The Advanced user pin code is 1234. Additional menu items for the user are
now visible.
1234
Advanced user
User pin code
The User pin code is 0000.
0000
User
To access the installer settings
1 Set the user permission level to Installer.
2 Go to [9]: Installer settings.
To modify an overview setting
Example: Modify [1‑01] from 15 to 20.
Most settings can be configured via the menu structure. If for any reason it is
required to change a setting using the overview settings, then the overview
settings can be accessed as follows:
1 Set the user permission level to Installer. See "To change
the user permission level"[4109].
—
2 Go to [9.I]: Installer settings > Overview field
settings.
