8 | Configuration
Installer reference guide
178
ERGA04~08DAV3(A) + EHVH04+08SU18+23DA6V7
Daikin Altherma 3 R F
4P618956-1 – 2020.03
# Code Description
[9.G] N/A Disable protections:
▪ 0: No
▪ 1: Yes
Forced defrost
Forced defrost
Manually start a defrost operation.
# Code Description
[9.H] N/A Do you want to start a defrost operation?
▪ Back
▪ OK
NOTICE
Forced defrost start-up. You can only start forced defrost when the heating
operation has been running for a while.
Overview field settings
All settings can be done using the menu structure. If for any reason it is required to
change a setting using the overview settings, then the overview settings can be
accessed in the field settings overview [9.I]. See "To modify an overview
setting"[4110].
8.5.10 Operation
To enable or disable functionalities
In the operation menu, you can separately enable or disable functionalities of the
unit.
# Code Description
[C.1] N/A Room:
▪ 0: Off
▪ 1: On
[C.2] N/A Space heating/cooling:
▪ 0: Off
▪ 1: On
[C.3] N/A Tank:
▪ 0: Off
▪ 1: On
