Daikin EHVH08SU23DA6V7 [17/240] Indoor unit
![Daikin EHVH08SU23DA6V7 [17/240] Indoor unit](/views2/1787402/page17/bg11.png)
3 | About the box
Installer reference guide
17
ERGA04~08DAV3(A) + EHVH04+08SU18+23DA6V7
Daikin Altherma 3 R F
4P618956-1 – 2020.03
3.3 Indoor unit
INFORMATION
This unit has been tested and approved according to BSEN12897:2016
3.3.1 To unpack the indoor unit
1 2
8×
3.3.2 To remove the accessories from the indoor unit
1×
4×
8×
1×
1× 1×
4× 1×
1× 1× 1× 1×
a b c d e
j k lf g h i
a Shut-off valves for water circuit
b Overpressure bypass valve
c Tundish (to mount onto the pressure relief valve discharge pipe)
d Brass compression coupler
e Discharge pipe (for pressure relief valve)
f General safety precautions
g Addendum book for optional equipment
h Indoor unit installation manual
i Operation manual
j Sealing rings for shut-off valves (space heating water circuit)
k Sealing rings for field-supplied shut-off valves (domestic hot water circuit)
l Sealing tape for low voltage wiring intake
3.3.3 To handle the indoor unit
Use the handles at the back and at the bottom to carry the unit.
