8 | Configuration
Installer reference guide
114
ERGA04~08DAV3(A) + EHVH04+08SU18+23DA6V7
Daikin Altherma 3 R F
4P618956-1 – 2020.03
Item Description
21
21
The temperatures are shown in circles. If the circle is grey,
the corresponding operation (example: space heating) is
currently not active.
Outdoor unit
a2
a3
a1
a1
: Outdoor unit
a2
: Quiet mode active
a3 Measured ambient temperature
Indoor unit /
domestic hot
water tank
b1
b2
b1 Indoor unit:
▪ : Floor-standing indoor unit with integrated tank
▪ : Wall-mounted indoor unit with separated tank
▪ : Wall-mounted indoor unit
b2 Water pressure
Space
operation
mode
c ▪ : Cooling
▪ : Heating
Disinfection /
Powerful
d
▪ : Disinfection mode active
▪ : Powerful operation active
Date / time e Current date and time
Holiday f
: Holiday mode active
Main zone
g3
g1
g4
g2
g1 Heat emitter type:
▪ : Underfloor heating
▪ : Fancoil unit
▪ : Radiator
g2 Leaving water temperature setpoint
g3 Room thermostat type:
▪ : Daikin user interface used as room thermostat
▪ : External control
▪ Hidden: Leaving water temperature control
g4 Measured room temperature
Additional
zone
h3
h1
h2
h1 Heat emitter type:
▪ : Underfloor heating
▪ : Fancoil unit
▪ : Radiator
h2 Leaving water temperature setpoint
h3 Room thermostat type:
▪ : External control
▪ Hidden: Leaving water temperature control
