![Einhell RT-XM 305 U [22/104] Intended use](/views2/1078977/page22/bg16.png)
4. Intended use
The universal saw is designed for cross-cutting wood
and plastic. In accordance with the operating
instructions the equipment can also be used to saw
hollow metal profiles with a rectangular cross-section.
Sawing metal profiles may only be carried out with
crosscuts. The equipment is expressly not permitted
to saw metal with a tensile strength of more than 400
N/mm², hardened metal, combustible and reactive
metals (such as magnesium and magnesium alloys),
all kinds of round materials and firewood.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse.
The user / operator and not the manufacturer will be
liable for any damage or injuries of any kind caused
as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or industrial
businesses or for equivalent purposes.
The equipment is to be operated only with suitable
saw blades. It is prohibited to use any type of cutting-
off wheel.
To use the equipment properly you must also observe
the safety regulations, the assembly instructions and
the operating instructions to be found in this manual.
All persons who use and service the equipment have
to be acquainted with this manual and must be
informed about the machine’s potential hazards. It is
also imperative to observe the accident prevention
regulations in force in your area. The same applies for
the general rules of health and safety at work.
The manufacturer will not be liable for any changes
made to the equipment nor for any damage resulting
from such changes. Even when the equipment is
used as prescribed it is still impossible to eliminate
certain residual risk factors. The following hazards
may arise in connection with the machine’s
construction and design:
Contact with the saw blade in the uncovered saw
zone.
Reaching into the running saw blade (cut
injuries).
Kick-back of workpieces and parts of workpieces.
Saw blade fracturing.
Catapulting of faulty carbide tips from the saw
blade.
Damage to hearing if ear-muffs are not used as
necessary.
Harmful emissions of metal and wood dust when
used in closed rooms.
Cut injuries through contact with chips and
workpieces.
Eye injuries caused by small metal chips.
5. Technical data
AC motor: 230V ~ 50Hz
Power: 1800 W
Operating mode: S1
Idle speed n
0
: 2,500 min
-1
Carbide saw blade: ø 250 x ø 30 x 2.2 mm
Number of teeth: 48
Swiveling range: -52° / 0°/ +60°
Miter cut: 0° to 45° to the left
Saw width at 90°:
Wood: 305 x 75 mm
Metal: 105 x 75 mm
Saw width at 45°:
Wood: 210 x 75 mm
Metal: 70 x 75 mm
Saw width at 2 x 45° (double miter cut):
Wood: 210 x 40 mm
Metal: 70 x 40 mm
Weight: approx. 17.5 kg
Sound and vibration
Sound and vibration values were measured in
accordance with EN 13898.
L
pA
sound pressure level 93.7 dB(A)
K
pA
uncertainty 2 dB
L
WA
sound power level 108.5 dB(A)
K
pA
uncertainty 2 dB
Wear ear-muffs.
The impact of noise can cause damage to hearing.
“The quoted values are emission values and not
necessarily reliable workplace values. Although there
is a correlation between emission and immission
levels it is impossible to draw any certain conclusions
as to the need for additional precautions.
Factors with a potential influence on the actual
immission level at the workplace include the duration
of impact, the type of room, and other sources of
22
GB
