CL-4
PREPARATION
PREPARATION
PFP:00002
Special Service Tools
BCS000KN
Tool number
(Renault tool number)
Tool name
Description
ST20050240
Diaphragm spring adjusting wrench
Inspecting diaphragm spring of
clutch cover
EM07020000
Clutch aligner
Installing clutch cover and disc
KV30101000
Clutch aligner
a:15.9mm(0.626in)dia
b:19.8mm(0.780in)dia
Installing clutch disc
ZZA0508D
PCIB0017E
ZZA1178D
