NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
CL-5
D
E
F
G
H
I
J
K
L
M
A
B
CL
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
NVH Troubleshooting Chart
BCS000KO
Use the chart below to help you find the cause of the symptom. The numbers indicate the order of the inspec-
tion. If necessary, repair or replace these parts.
CLUTCH
Reference page
CL-6.
CL-8
.
CL-9
.
EM-70
.
CL-10
CL-11.
CL-11
.
CL-11
.
CL-11
.
CL-11
.
CL-11
.
CL-11
CL-11
CL-12.
CL-12
.
CL-12
.
CL-11
SUSPECTED PARTS (Possible cause)
CLUTCH PEDAL (Free play out of adjustment)
CLUTCH LINE (Air in line)
MASTER CYLINDER PISTON CUP (Damaged)
ENGINE MOUNTING (Loose)
RELEASE BEARING (Worn, dirty or damaged)
CLUTCH DISC (Out of true)
CLUTCH DISC (Runout is excessive)
CLUTCH DISC (Lining broken)
CLUTCH DISC (Dirty or burned)
CLUTCH DISC (Oily)
CLUTCH DISC (Worn out)
CLUTCH DISC (Hardened)
CLUTCH DISC (Lack of spline grease)
DIAPHRAGM SPRING (Damaged)
DIAPHRAGMSPRING(Outoftipalignment)
PRESSURE PLATE (Distortion)
FLYWHEEL (Distortion)
Symptom
Clutch grabs/chatters 1 2 2 2 2 2
Clutch pedal spongy 1 2
Clutch noisy 1
Clutch slips 1 2 2 3 4 5
Clutch does not disengage 1 2 3 4 4 4 4 4 4 5 5 6
