FSU-14
FRONT SUSPENSION MEMBER
INSTALLATION
● Refer to FSU-5, "FRONT SUSPENSION ASSEMBLY" for tightening torque. Tighten in the reverse order
of removal.
● After finishing work, perform final tightening of each part under unladen condition with tyres on level
ground. Check wheel alignment. Refer to FSU-6, "
Wheel Alignment" .
