PREPARATION PFP:00002
Special Service Tools
BES0002H
Description Application
CCK gauge attachment
KV991040S1
1 KV99104020 Adapter A
2 KV99104030 Adapter B
3 KV99104040 Adapter C
4 KV99104050 Adapter D
5 KV99104060 Plate
6 KV99104070 Guide bolt
7 KV99104080 Spring
8 KV99104090 Center plate
Measuring wheel alignment
Strut attachment
ST35652000
Disassembling and assembling strut
GG94310000
Flare nut torque wrench
a: 10 mm (0.39 in)
Removing and installing brake lines
ZZA1167D
ZZA0807D
NT406
