Daikin RXYTQ10U7YF [102/152] Electrical installation
![Daikin RXYTQ10U7YF [102/152] Electrical installation](/views2/1791822/page102/bg66.png)
19 | Electrical installation
Installer and user reference guide
102
RXYTQ8~16U7YF
VRV IV+ heat pump for high ambient temperatures
4P561157-1A – 2020.10
b a
A
b a
c
c
c
d
c
d
c
8 HP 10~16 HP
A
A
a Transmission wiring (possibility 1)
(a)
b Transmission wiring (possibility 2)
(a)
. Fix to pipe insulation with tie wraps.
c Tie wrap. Fix to factory-mounted low voltage wiring.
d Tie wrap.
(a) Knockout hole has to be removed. Close the hole to avoid small animals or dirt from
entering.
X1A
c
d
a b a b
8 HP 10~16 HP
Fix to the indicated plastic brackets using field supplied clamping material.
a Wiring between the units (indoor-outdoor) (F1/F2 left)
b Internal transmission wiring (Q1/Q2)
c Plastic bracket
d Field supplied clamps
