20 | Configuration
Installer and user reference guide
117
RXYTQ8~16U7YF
VRV IV+ heat pump for high ambient temperatures
4P561157-1A – 2020.10
If the system needs to be running under power consumption limitation conditions
when an external signal is sent to the unit, this setting defines the level power
consumption limitation that will be applied for step1. The level is according to the
table.
[2‑30] Power consumption limitation (approximately)
1 60%
2 65%
3 (default) 70%
4 75%
5 80%
6 85%
7 90%
8 95%
[2‑31]
Power consumption limitation level (step 2) via the external control adaptor
(DTA104A61/62).
If the system needs to be running under power consumption limitation conditions
when an external signal is sent to the unit, this setting defines the level power
consumption limitation that will be applied for step2. The level is according to the
table.
[2‑31] Power consumption limitation (approximately)
1 (default) 40%
2 50%
3 55%
[2‑32]
Forced, all time, power consumption limitation operation (no external control
adaptor is required to perform power consumption limitation).
If the system always needs to be running under power consumption limitation
conditions, this setting activates and defines the level power consumption
limitation that will be applied continuously. The level is according to the table.
[2‑32] Restriction reference
0 (default) Function not active.
1 Follows [2‑30] setting.
2 Follows [2‑31] setting.
[2‑81]
Cooling comfort setting.
This setting is used in conjunction with setting [2‑8].
[2‑81] Cooling comfort setting
0 Eco
1 (default) Mild
2 Quick
