18 | Piping installation
Installer and user reference guide
73
RXYTQ8~16U7YF
VRV IV+ heat pump for high ambient temperatures
4P561157-1A – 2020.10
Total piping length 1000m/500m
Example 1.1
▪ a+b+c+d+e+f+g+h+i+j+k+l+m+n+p≤1000m
Example 2.1
▪ a+b+c+d+e+f+g+h+i+j+k+l+m+n+p≤500m
▪ Between outdoor branch and outdoor unit (only in case >16HP)
Actual piping length 10m
Example 3
▪ r, s, t≤10m; u≤5m
Equivalent length 13m
Maximum allowable height difference
H1 ≤50m (40m)
(if outdoor is located below indoor units)
Conditional extension up till 90m is possible without additional option
kit:
▪ In case the outdoor location is higher than indoor: extension is possible
up till 90m and following 2conditions must be fulfilled:
- Liquid piping size up (see table "Size up" in "E: Piping between
refrigerant branch kit and indoor unit"[468]).
- Dedicated setting on outdoor unit is required (see [2‑49] in "Mode 2:
Field settings"[4114]).
▪ In case the outdoor location is lower than indoor: extension is possible
up till 90m and following 6conditions must be fulfilled:
- 40~60m: minimum connection ratio connected: 80%.
- 60~65m: minimum connection ratio connected: 90%.
- 65~80m: minimum connection ratio connected: 100%.
- 80~90m: minimum connection ratio connected: 110%.
- Liquid piping size up (see table "Size up" in "E: Piping between
refrigerant branch kit and indoor unit"[468]).
- Dedicated setting on outdoor unit is required (see [2‑35] in "Mode 2:
Field settings"[4114]).
H2 ≤30m
H3 ≤5m
Maximum allowable length after branch
The pipe length from the first refrigerant branch kit to the indoor unit ≤40 m.
Example 1.1: unit 8: b+c+d+e+f+g+p≤40m
Example 1.2: unit 6: b+h≤40m, unit 8: i+k≤40m
Example 1.3: unit 8: i≤40m
However, extension is possible if all below conditions are met. In this case
limitation can be extended up to 90m.
