GB
- 19 -
Caution!
When using equipment, a number of safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety information with due care.
Keep these operating instructions in a safe place
so that the information is available at all times. If
you give the equipment to any other person, hand
over these operating instructions and the safety
information as well. We cannot accept any liabi-
lity for damage or accidents which arise due to
failure to follow these instructions and the safety
information.
1. Layout
1. Feet
2. Diamond cutting wheel
3. Trough
4. Work table
5. Angle stop
6. Stop rail
7. Guide rail
8. Cutting wheel guard
9. Handle
10. Clamping screw for angle setting
11. Clamping screw for cutting wheel guard
12. Clamping screw
13. Cooling water pump
14. Hose
15. Motor
16. On/Off switch
17. Angle scale
18. Transport handle
19. Transport wheels
2. Items supplied
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
present).
•
Check to see if all the items are supplied.
•
Inspect the equipment and accessories for
damage in transit.
•
If possible, keep the packaging until the end
of the guarantee period.
IMPORTANT
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, plastic sheets and small parts. There is
a risk of choking and suff ocating!
•
Original operating instructions
•
Safety information
•
Tile cutting machine
•
Trough (3)
•
Cooling water pump (13)
•
Angle stop (5)
•
Feet (1)
3. Intended use
The tile cutting machine is designed for the
standard cutting of small and medium-size tiles
(glazed tiles, ceramic tiles or similar) which can
be accommodated by the size of the machine. It
is designed for DIY applications and craft busi-
nesses in particular. It should never be used for
cutting wood or metal. The machine should be
used exclusively for its intended purpose. Any
other use is deemed to be a case of misuse. The
user/operator and not the manufacturer will be
held liable for damage and/or injuries of any kind
that result from such misuse. The machine is to
be operated only with suitable cutting wheels.
Saw blades should never be used. Intended use
also includes complying with the safety informa-
tion, the assembly instructions and the operating
instructions contained in the operating manual. All
persons who use and service the equipment have
to be acquainted with these operating instructions
and must be informed about the equipment‘s
potential hazards. In addition, strict compliance
with the accident prevention regulations in force
in your area, as well as all other general rules
of health and safety at work, is imperative. The
manufacturer‘s liability shall be deemed void if the
machine is modifi ed in any way and the manu-
facturer shall accept no liability for any damages
arising as a result of modifi cations. Even when the
equipment is used as prescribed it is still impos-
sible to eliminate certain residual risk factors. The
following hazards may arise in connection with
the machine‘s construction and design:
•
Contact with the diamond cutting wheel whe-
re it is not covered.
•
Reaching into the diamond cutting wheel
while it is turning.
•
Defective diamond tips flying off the cutting
Anl_TE_TC_620_U_SPK7.indb 19Anl_TE_TC_620_U_SPK7.indb 19 24.07.12 08:2724.07.12 08:27
