Einhell TE-TC 620 U [20/92] Important information
![Einhell TE-TC 620 U [20/92] Important information](/views2/1079636/page20/bg14.png)
GB
- 20 -
wheel or catapulting of workpieces and parts
of workpieces.
•
Damage to hearing if essential ear-muffs are
not used.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or indust-
rial businesses or for equivalent purposes.
4. Important information
4.1. General
Please read the operating instructions carefully
and observe the information provided. It is im-
portant to consult these instructions in order to
acquaint yourself with the equipment, its proper
use and safety information.
4.2. Additional safety instructions
•
Set up the machine on a level, non-slip floor.
Make sure that the machine does not wobble.
•
Check that the voltage on the rating plate is
the same as your supply voltage. Only then
are you to insert the power plug in the socket-
outlet.
•
Wear safety goggles.
•
Wear ear-muffs.
•
Wear safety gloves.
•
Never use cracked diamond cutting wheels.
Replace immediately.
•
Never use segmented cutting wheels.
•
Important: The cutting wheel will continue to
rotate after the machine is switched off!
•
Never apply side pressure to the diamond
cutting wheel in order to bring it to a halt.
•
Important: The diamond cutting wheel must
be cooled with water at all times.
•
Always pull out the power plug before chan-
ging the cutting wheel.
•
Use only suitable diamond cutting wheels.
•
Never leave the machine unattended in
rooms with children.
•
Always pull out the power plug before exami-
ning the electric motor compartment system.
•
Disorder in the work area can easily lead to
accidents.
•
Make sure that you stand squarely and solidly
while working. Avoid abnormal body positions
and always keep your balance.
•
If the cutting wheel becomes jammed, switch
off the equipment and disconnect it from the
power supply; only then are you to remove the
workpiece.
WARNING
Read all the safety information and instruc-
tions. Failure to adhere to the safety information
and instructions set out below may result in elec-
tric shock, fi re and/or serious injury. Keep all the
safety information and instructions in a safe
place for future use.
5. Technical data
Motor rating: ............................. 900 W S2 30 min
Motor speed: .......................................2950 min
-1
AC motor: ...................................... 230 V ~ 50 Hz
Insulation material class: ......................... Class B
Protection type: ........................................... IP 54
Table size: .....................................610 x 325 mm
Working height: ...................................... 700 mm
Cut length: .............................................. 620 mm
Jolly length: ............................................ 620 mm
Max. workpiece thickness 90°: .................. 30 mm
Max. workpiece thickness 45°: .................. 25 mm
Diamond cutting wheel: .......... ø 200 x ø 25.4 mm
Weight .........................................................34 kg
A load factor of S2 30 min (intermittent periodic
duty) means that you may operate the motor
continuously at its nominal power level (900 W)
for no longer than the time stipulated on the spe-
cifi cations label (30 minutes ON period). If you fail
to observe this time limit the motor will overheat.
During the OFF period the motor will cool again to
its starting temperature.
Sound and vibration
The noise emission values were measured in ac-
cordance with EN 61029.
L
pA
sound pressure level ........................ 72 dB(A)
K
pA
uncertainty .............................................3 dB
L
WA
sound power level ........................... 85 dB(A)
K
WA
uncertainty .............................................3 dB
