GB
- 21 -
Reduce noise generation and vibration to a
minimum!
•
Use only equipment that is in perfect condi-
tion.
•
Maintain and clean the equipment regularly.
•
Adapt your way of working to the equipment.
•
Do not overload the equipment.
•
Have the equipment checked if necessary.
•
Switch off the equipment when not in use.
•
Wear gloves.
Residual risks
Even if you use this electric power tool in
accordance with the instructions, certain
residual risks cannot be eliminated. The fol-
lowing hazards may arise in connection with
the equipment‘s construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is applied.
3. Health damage caused by hand-arm vibra-
tions if the equipment is used over a longer
period or is not properly guided and maintai-
ned.
6. Before starting the equipment
•
The machine must be set up so that it stands
firmly, i.e. it must be securely screwed to a
work bench, to the base frame supplied, or
similar.
•
All covers and safety devices have to be pro-
perly fitted before the equipment is switched
on.
•
The cutting wheel must rotate smoothly.
•
Check that the voltage on the rating plate is
the same as your supply voltage before you
connect the equipment to the power supply.
7. Assembly and operation
7.1 Unfolding the base frame (Fig. 2)
•
To set up the equipment on its feet (1), press
the latching button (a) and lower the respec-
tive feet (1) until they latch in the intended
position. To fold up the feet (1), proceed in
reverse order.
7.2 Fitting the cooling water pump (Fig. 4 - 6)
•
First place the container (a) for the cooling
water pump (13) in the intended position on
the trough (3).
•
Place the cooling water pump (13) - with the
suction cups pointing down - into the contai-
ner (a).
•
Then fasten the hose to the intended posi-
tions as shown in Fig. 5 and 6.
Important!
To guarantee proper operation, the cooling water
hose (14) must not be kinked during installation.
Caution!
It must be impossible for the cable and the coo-
ling water hose to get into the cutting area.
7.3 Fitting the transport aids (Fig. 7 - 9)
•
Fit the transport wheels (19), the parking foot
(20) and the transport handle (18) as shown
in Figs. 7/8/9.
7.4 Fitting the stop rail and the angle stop
(Fig. 10)
•
First push the stop rail (6) onto the guides (a)
as shown and fasten.
•
Then you can push the angle stop (5) into the
guide (b) and fasten in any position.
7.5 On/Off switch (Fig. 3/4)
•
To switch on, press the „1“ on the On/Off
switch (16).
•
Before you begin cutting, wait until the cutting
wheel has reached maximum speed and the
cooling water pump (13) has started supply-
ing water to the cutting wheel.
•
To switch off, press the „0“ on the On/Off
switch (16).
7.6 Making 90° cuts (Fig. 11/12)
•
Slacken the handle screw (28) and push the
angle stop (5) into the required position and
set the angle to 0° degrees, then tighten the
handle screw (28) again in order to secure
the angle stop (5).
•
Then slacken the clamping screw (12) and
push it to the required position.
•
You can now move the machine head (29) by
the handle (9) to the rear.
•
Place a tile against the stop rail (6) and the
angle stop (5).
•
Switch on the machine.
•
Important: Wait until the cooling water has
reached the cutting wheel (2).
