31
NOTE:
Once the set temperature has been reached, the
HEATING control lamp goes off. The power on lamp
remains on and shows that the device is working.
8. Now ll the deep-fry basket. Please ensure that the basket
is not lled above the hot fat. Open the lid and insert the
basket with the items to be fried carefully into the recess.
9. Now close the lid. Release the handle (by pushing the but-
ton (12) on the handle). The deep-fry basket is now in the
hot fat.
NOTE:
During the deep-frying process the HEATING control
lamp switches on and off several times. This is nor-
mal and it indicates that the temperature is controlled
by the thermostat and is being maintained.
The frying times are to be found on the packaging of
the food or in the recipe.
10. After the frying time has expired, you can allow the oil
to drain off the deep-fried food. To do so, reach into the
recess and pull the handle (13) up, until it latches. This will
lift the basket.
11. Open the lid carefully.
WARNING:
As it is possible that hot steam will be released.
12. Now remove the deep-frying basket.
Switching Off
Set the temperature regulator to the minimum setting (OFF).
Switch the appliance off at the main switch (O).
Remove the mains plug from the socket.
Allow the frying oil a considerable time to cool down. Before
continuing to use the full frying pot, please ensure that it is
no longer at a dangerous temperature.
Mains Lead Take-up Device
Wind the mains lead up again on the rear of the deep fat fryer.
Cleaning
WARNING:
Always pull out the plug from the mains socket before
cleaning and wait until the unit has cooled down.
Under no circumstances should you immerse the device
in water for cleaning purposes. Otherwise this might result
in an electric shock or re.
CAUTION:
Do not use a wire brush or any abrasive items.
Do not use any acidic or abrasive detergents.
Deep frying fat container
In order to change the oil, pull out the deep frying fat con-
tainer and pour the oil out at the side.
The frying fat container and deep frying basket can be
cleaned in the normal way in soapy water.
Reinsert the frying fat container in such a way that the MIN
and MAX Mark is located at the rear end of the deep fat
fryer.
Housing
The lid of the deep fryer can be removed. This makes it
easier to clean.
Clean the housing and lid after use with a damp cloth and
domestic washing-up liquid if necessary. Do not remove the
lid seal. It might tear.
Replace the lid after cleaning. Make sure that the spring sits
in the recess.
Ensure that the parts are completely dry before re-using the
appliance and before storage.
Changing the Odour and Fat Vapour Filter
The lter in the lid can be replaced.
Remove lter cover (3).
Replace the lter.
Then reassemble the cover.
NOTE:
When these lters have been used up it is possible to cut
universal lters to size, e.g. from cooker hoods.
Technical Data
Model: ....................................................................... FR 2224 CB
Power supply: ...........................................................230 V, 50 Hz
Power consumption: ......................................................... 1800 W
Protection class: ........................................................................... I
Filling quantity: ...............................................................max. 2.5 l
Net weight: .........................................................................2.80 kg
Subject to technical changes without prior notice!
This device has been tested according to all relevant current
CE guidelines, such as electromagnetic compatibility and low
voltage directives, and has been constructed in accordance
with the latest safety regulations.
