Performance Curves
-216-
heating performance curves-AB602ACERA/AU60NAIERA
3000
4000
5000
6000
7000
8000
9000
10000
11000
12000
13000
14000
15000
16000
17000
16/10 18/12 20/14.5 21/15 22/16 24/17 26/18
indoor temp.
heating capacity and power input (W)
-6/-7 heating capacity
-6/-7 power input
-4/-5 heating capacity
-4/-5 power input
-1/-2 heating capacity
-1/-2 power input
1/0 heating capacity
1/0 power input
6/5 heating capacity
6/5 power input
7/6 heating capacity
7/6 power input
12/10 heating capacity
12/10 power input
16/15 heating capacity
16/15 power input
27/18 heating capacity
27/18 power input
cooling performance curves-AB602ACERA/AU60NAIERA
2000
3000
4000
5000
6000
7000
8000
9000
10000
11000
12000
13000
14000
15000
16000
18/12 20/14 22/16 25/18 27/19 30/22 32/23
indoor temp.
cooling capacity and power input (W)
20 cooling capacity
20 power input
25 cooling capacity
25 power input
32 cooling capacity
32 power input
35 cooling capacity
35 power input
40 cooling capacity
40 power input
