– 39 –
English
PARTS LIST
10” (250mm) JOBSITE TABLE SAW MODEL NO. C10RD
PARTS LIST FOR SCHEMATIC Always order by I.D. Number
Parts NO. I.D. Description Size QTY Parts NO. I.D. Description Size QTY
326833 08V4 RUBBER 1 726600 0KMV HEX. NUT M10*1.5 T=8 1
726434 08VH CORD CLAMP 1 726601 0KMW HEX. NUT M10*1.5 T=4 1
726437 09JK WRENCH 1 726603 0KMY HEX. NUT M8*1.25 T=6.5 1
326834 0B22 HEIGHT REGULATING BOLT 1 726612 0KQJ CROWN NUT M8*1.25 T=12.5 1
726437 0B23 SADDLE 1 726620 0KRQ
SERRATED TOOTHED HEXAGON FLANGE
NUT
M6*1.0 T=6 7
726439 0B24 SPRING 1 726622 0KRX HEXAGON NUT AND FLAT WASHER M6*1.0 1
326835 0B25 POINTER BRACKET 1 326849 0KT5 GUARD-CORD 1
726444 0B3R WRENCH 1 326427 0KTD STRAIN RELIEF 2
726446 0B99 SPACER 1 726633 0LMK LOCKING CABLE TIE 1
726447 0B9C PLUNGER HOUSING 1 326850 0LN4 WIRE CONNECTOR 1
326836 0B9M STRAP 6 326851 0LVP FERRITE CORE 1
326837 0B9S BRACKET 1 326852 0M0H CAPACITOR 1
726449 0B9W BRACKET 1 326853 26BN CR. RE. PAN HD. SCREW M6*1.0-25 1
726450 0BA4 SPACER 1 726782 287H RETAINING CLIP 1
726454 0BAC SET NUT 1 326854 28GK ARBOR COLLAR 1
726478 0J4F FLAT WASHER φ8X16-2.5 1 326855 28GV ANGLE ROD 1
726479 0J4H FLAT WASHER φ10*30-0.2 2 326856 28KD TILT POINTER 1
326838 0J4U FLAT WASHER φ6*18-1.5 4 326857 28XW LEVER BRACKET 1
726488 0J70 FLAT WASHER 1/4*3/4-7/64 2 326858 28XZ COVER 1
726489 0J72 FLAT WASHER 1/4*5/8-1/16 1 326859 290X LEAD WIRE ASS’Y 1
726495 0J8D FLAT WASHER 3/8*3/4-5/64 2 326860 290Y LEAD WIRE ASS’Y 1
326839 0J8K FLAT WASHER 1/4*3/4-1/16 2 726873 293H PUSH BLOCK 1
326840 0J9H SPRING WASHER φ1/4” 6 326861 29KV C-RING 1
726507 0JCA SPRING PIN 1 326862 2BA3 MOTOR ASS’Y 1
326841 0JCR SPRING PIN 1 326863 2BHA SPLITTER BRACKET 1
326842 0JFC SELF-LOCKING RING 2 326864 2BHB LEVER 1
726525 0JPF HEX. HD. BOLT M6*1.0-25 4 326865 2BJJ TABLE 1
726535 0JXL HEX. SOC. SET SCREW M10*1.5-12 1 326866 2BJX DUST COLLECTOR 1
325713 0JYN HEX. SOC. COUNTERSUNK HD. SCREW M6*1.0-25 6 326867 2BKT TRIGGER VALVE SEAT 1
726320 0K0Z HEX. HD. SCREW AND WASHER M8*1.25-16 4 326868 2BKU DUST GUARD 1
726319 0K16 HEX. HD. SCREW AND WASHER M8*1.25-16 1 326869 2BKV FLOOR PLATE 1
326843 0K1J HEX. HD. SCREW AND WASHER M6*1.0-16 2 326870 2C36 POWER CABLE 1.0*2C-2500 1
726538 0K25 HEX.SOCKET HD.CAP SCREWS M5*0.8-20 1 326871 2C4U PUSH BUTTON SWITCH ASS’Y 1
726543 0K3G CR.RE. PAN HD. SCREW & WASHER M5*0.8-12 1 326872 2CCF MOTOR BRACKET 1
326844 0K56 CR. RE. COUNT HD. SCREW M5*0.8-12 2 326873 2CTZ LOCK KNOB 1
726561 0K8C CR. RE.COUNT HD. TAPPING SCREW M4*18-10 7 326874 2DGS SCALE 1
726564 0K94 CR. RE. TRUSS HD. TAPPING SCREW M5*12-16 4 326875 2DVK ARBOR COLLAR 1
726570 0KA4 CR.RE. PAN HD. TAPPING SCREW M4*16-16 2 326876 2FSW BLADE 1
325722 0KA5 CR.RE. PAN HD. TAPPING SCREW M4*16-20 6 326877 2G1V INSERT 1
326845 0KA6 CR.RE. PAN HD. TAPPING SCREW M5*12-10 3 326878 2G2K CONNECTOR 1
326846 0KDM CR. RE. PAN HD. SCREW M5*0.8-20 4 326879 2G2M SPACER 1
726581 0KDR CR. RE. PAN HD. SCREW M5*0.8-10 1 326880 2G39 DUST TUBE. 1
326847 0KEM CR. RE. PAN HD. SCREW M6*1.0-40 1 326881 2G3E SPACER 2
726588 0KHZ CAP HD. SQ.NECK BOLT M6*1.0-12 1 326882 2G47 BODY SHELL 1
726589 0KJ4 CAP HD. SQ.NECK BOLT M6*1.0-35 1 326883 2K8J PARALLEL BRACKET ASS’Y 1
726590 0KJ5 CAP HD. SQ.NECK BOLT M6*1.0-80 1 326884 2K8S HAND WHEEL ASS’Y 1
326848 0KM0 RIVET 2 326885 2K8W BLADE GUARD ASS’Y 1
726596 0KMR HEX. NUT M5*0.8 T=4 1 326886 2K8X MITER GAUGE ASS’Y 1
726597 0KMS HEX. NUT M6*1.0 T=5 1 326887 2K8Y AUXILIARY PARALLEL BRACKET ASS’Y 1
