18
b. Central control system
Control 16 groups indoor units separately and display state of each group;
ON/OFF synchronously function can control all the indoor units run/stop
at the same time. Can realize the following mode when combined with
the standard controller:
1. The latter command between group controller and the standard controller
is in priority.
2. Group controller can set the central mode to control all indoor units centrally,
and the standard controller only can set ON/OFF mode.
3.Group controller can be in LOCK mode
YR-E12
group control+individual control
Group controller:
Indoor unit
Power
Group controller
controller
controller
