6.12.4 Features
1. Simultaneous ON/OFF with indoor unit by the indoor unit wired controller
2. HRV independent operation when indoor unit is off by indoor wired controller.
3. Automatic ventilation mode changeover: Auto/Heat recovery/Bypass
4. Fan speed changeover by indoor wired controller
5. Preheating/cooling operation
6. Filter icon display when the filter needs to be cleaned
7. Standard HRV wired controller
8. Timer function
9. Realize central control with the MRVII central controller
10. HRV can be used individually without indoor unit
outdoor
supply air to
indoor
indoor return air
indoor return air
flows to outdoor
outdoor fresh air
air inelt fan
discharging fan
heat exchange
element
indoor
24
