Haier AV26NMVERA Инструкция по монтажу онлайн [354/531] 616694
![Haier AV26NMVERA Инструкция по монтажу онлайн [354/531] 616694](/views2/1816541/page354/bg162.png)
TC PI TC PI TC PI TC PI TC PI TC PI
℃DB ℃WB
KW KW KW KW KW KW KW KW KW KW KW KW
AV34NMVERA heating mode
capacity
factor
outdoor temp.
indoor temp. (℃DB)
16.0 18.0 20.0 21.0 22.0 24.0
7.0 6.0 108.0 25.8 108.0 26.3 108.0 27.0 108.0 27.2 108.0 27.4 103.6 26.3
9.0 7.9 111.6 26.3 111.6 26.7 111.6 27.2 111.6 27.4 110.9 27.4 103.6 25.2
11.0 9.8 115.4 26.5 115.4 27.0 115.4 27.4 114.9 27.4 110.9 26.3 103.6 24.3
13.0 11.8 118.4 26.7 118.4 27.2 119.0 27.2 114.9 26.3 110.9 25.2 103.6 23.4
15.0 13.7 123.0 27.0 123.0 27.4 119.0 26.3 114.9 25.4 110.9 24.3 103.6 22.5
19.0 14.2 123.0 25.2 123.0 27.2 119.0 25.4 114.9 24.4 110.9 23.5 103.6 21.8
21.0 15.0 123.0 25.4 123.0 26.4 119.0 24.1 114.9 23.6 110.9 22.8 103.6 21.5
-14.7 -15.0 66.8 21.3 66.8 22.1 66.8 23.0 66.8 23.2 66.8 23.6 66.8 24.5
-12.6 -13.0 70.6 22.1 70.6 23.0 70.6 23.6 70.6 23.8 70.6 24.3 70.6 25.0
-10.5 -11.0 74.6 23.0 74.6 23.6 74.6 24.3 74.6 24.5 74.6 25.0 74.6 25.6
-9.5 -10.0 76.8 23.2 76.8 23.8 76.8 24.5 76.8 25.0 76.8 25.2 76.8 25.8
-8.5 -9.1 78.5 23.4 78.5 24.1 78.5 24.7 78.5 25.2 78.5 25.4 78.5 26.1
-7.0 -7.6 81.6 23.8 81.6 24.5 81.6 25.2 81.6 25.4 81.6 25.8 81.6 26.5
-5.0 -5.6 85.4 24.5 85.4 25.0 85.4 25.6 85.4 25.8 85.4 26.3 85.4 26.7
-3.0 -3.7 89.0 25.0 89.0 25.4 89.0 26.1 89.0 26.3 89.0 26.5 89.0 27.2
0.0 -0.7 94.8 25.6 94.8 26.1 94.8 26.5 94.8 27.0 94.8 27.2 94.3 27.6
3.0 2.2 100.3 26.1 100.3 26.5 100.3 27.2 100.3 27.4 100.3 27.6 94.3 25.8
5.0 4.1 104.3 26.3 104.3 27.0 104.3 27.4 104.3 27.6 101.1 26.7 94.3 24.7
7.0 6.0 108.0 26.7 108.0 27.2 108.0 27.6 104.6 26.5 101.1 25.6 94.3 23.6
9.0 7.9 111.6 27.0 111.6 27.4 108.0 26.5 104.6 25.6 101.1 24.5 94.3 22.7
11.0 9.8 115.4 27.2 114.9 27.4 108.0 25.4 104.6 24.5 101.1 23.6 94.3 21.9
13.0 11.8 118.4 27.4 114.9 26.3 108.0 24.5 104.6 23.6 101.1 22.7 94.3 21.0
15.0 13.7 121.7 27.0 114.9 25.4 108.0 23.6 104.6 22.7 101.1 21.9 94.3 20.3
19.0 14.2 121.7 26.2 114.9 24.5 108.0 23.0 104.6 21.8 101.1 21.1 94.3 19.8
21.0 15.0 121.7 25.4 114.9 23.5 108.0 22.2 104.6 21.5 101.1 20.4 94.3 19.3
-14.7 -15.0 66.8 22.7 66.8 23.4 66.8 24.1 66.8 24.5 66.8 24.7 66.8 25.4
-12.6 -13.0 70.6 23.4 70.6 24.1 70.6 24.7 70.6 25.0 70.6 25.4 70.6 26.1
-10.5 -11.0 74.6 24.1 74.6 24.7 74.6 25.4 74.6 25.6 74.6 25.8 74.6 26.5
-9.5 -10.0 76.8 24.3 76.8 25.0 76.8 25.6 76.8 25.8 76.8 26.1 76.8 26.7
-8.5 -9.1 78.5 24.5 78.5 25.2 78.5 25.8 78.5 26.1 78.5 26.3 78.5 27.0
-7.0 -7.6 81.6 25.0 81.6 25.6 81.6 26.1 81.6 26.5 81.6 26.7 81.4 27.2
-5.0 -5.6 85.4 25.4 85.4 26.1 85.4 26.5 85.4 26.7 85.4 27.2 84.2 27.6
-3.0 -3.7 89.0 25.8 89.0 26.5 89.0 27.0 89.0 27.2 89.0 27.4 84.4 26.5
0.0 -0.7 94.8 26.5 94.8 27.0 94.8 27.4 93.7 27.6 90.8 26.5 84.4 24.5
3.0 2.2 100.3 27.0 100.3 27.4 97.2 26.7 93.7 25.8 90.8 24.7 84.4 23.0
5.0 4.1 104.3 27.2 103.8 27.4 97.2 25.6 93.7 24.7 90.8 23.6 84.4 21.9
7.0 6.0 108.0 27.4 103.8 26.3 97.2 24.5 93.7 23.6 90.8 22.7 84.4 21.1
9.0 7.9 109.8 27.0 103.8 25.2 97.2 23.6 93.7 22.7 90.8 21.9 84.4 20.3
11.0 9.8 109.8 25.8 103.8 24.3 97.2 22.7 93.7 21.8 90.8 21.1 84.4 19.5
13.0 11.8 109.8 25.0 103.8 23.4 97.2 21.8 93.7 21.0 90.8 20.3 84.4 18.8
15.0 13.7 109.8 24.1 103.8 22.5 97.2 21.0 93.7 20.3 90.8 19.6 84.4 18.2
19.0 14.2 109.8 23.5 103.8 21.9 97.2 20.3 93.7 19.7 90.8 18.9 84.4 17.5
21.0 15.0 109.8 22.6 103.8 21.1 97.2 20.0 93.7 19.0 90.8 18.2 84.4 16.8
-14.7 -15.0 66.8 24.1 66.8 24.7 66.8 25.4 66.8 25.6 66.8 25.8 66.8 26.5
-12.6 -13.0 70.6 24.7 70.6 25.2 70.6 25.8 70.6 26.1 70.6 26.5 70.6 27.0
-10.5 -11.0 74.6 25.2 74.6 25.8 74.6 26.3 74.6 26.7 74.6 27.0 74.2 27.4
-9.5 -10.0 76.8 25.6 76.8 26.1 76.8 26.5 76.8 27.0 76.8 27.2 75.2 27.6
100
90
354
