TC PI TC PI TC PI TC PI TC PI TC PI
℃DB ℃WB
KW KW KW KW KW KW KW KW KW KW KW KW
AV34NMVERA heating mode
capacity
factor
outdoor temp.
indoor temp. (℃DB)
16.0 18.0 20.0 21.0 22.0 24.0
-8.5 -9.1 78.5 25.8 78.5 26.3 78.5 26.7 78.5 27.2 78.5 27.4 75.3 27.2
-7.0 -7.6 81.6 26.1 81.6 26.5 81.4 27.2 81.4 27.4 80.4 27.6 75.3 25.8
-5.0 -5.6 85.4 26.5 85.4 27.0 85.4 27.4 83.4 27.6 80.9 26.5 75.3 24.5
-3.0 -3.7 89.0 27.0 89.0 27.4 86.4 27.2 83.4 26.1 80.9 25.2 75.3 23.2
0.0 -0.7 94.8 27.4 91.9 27.0 86.4 25.2 83.4 24.3 80.9 23.2 75.3 21.5
3.0 2.2 97.3 26.7 91.9 25.2 86.4 23.4 83.4 22.5 80.9 21.7 75.3 20.1
5.0 4.1 97.3 25.6 91.9 24.1 86.4 22.5 83.4 21.6 80.9 20.8 75.3 19.3
7.0 6.0 97.3 24.5 91.9 23.0 86.4 21.5 83.4 20.8 80.9 20.0 75.3 18.6
9.0 7.9 97.3 23.6 91.9 22.1 86.4 20.7 83.4 20.0 80.9 19.3 75.3 17.9
11.0 9.8 97.3 22.7 91.9 21.3 86.4 19.9 83.4 19.3 80.9 18.6 75.3 17.2
13.0 11.8 97.3 21.9 91.9 20.5 86.4 19.2 83.4 18.5 80.9 17.9 75.3 16.6
15.0 13.7 97.3 21.1 91.9 19.6 86.4 18.5 83.4 17.9 80.9 17.3 75.3 16.1
19.0 14.2 97.3 20.4 91.9 19.3 86.4 17.8 83.4 17.2 80.9 16.6 75.3 15.7
21.0 15.0 97.3 19.8 91.9 18.4 86.4 17.3 83.4 16.7 80.9 16.0 75.3 14.9
-14.7 -15.0 66.8 25.4 66.8 26.1 66.8 26.5 66.8 26.7 66.8 27.0 65.2 27.6
-12.6 -13.0 70.6 26.1 70.6 26.5 70.6 27.0 70.6 27.2 69.6 27.6 65.8 26.5
-10.5 -11.0 74.6 26.5 74.6 27.0 74.4 27.4 72.8 27.6 70.7 26.7 65.8 24.7
-9.5 -10.0 76.8 26.7 76.8 27.2 75.4 27.6 73.1 27.0 70.7 25.8 65.8 23.8
-8.5 -9.1 78.5 27.0 78.5 27.4 75.8 27.2 73.1 26.3 70.7 25.2 65.8 23.4
-7.0 -7.6 81.4 27.2 80.2 27.6 75.8 26.1 73.1 25.0 70.7 24.1 65.8 22.3
-5.0 -5.6 84.8 27.6 80.5 26.3 75.8 24.5 73.1 23.6 70.7 22.7 65.8 21.1
-3.0 -3.7 85.4 26.7 80.5 25.0 75.8 23.4 73.1 22.5 70.7 21.7 65.8 20.1
0.0 -0.7 85.4 24.7 80.5 23.2 75.8 21.6 73.1 20.9 70.7 20.1 65.8 18.7
3.0 2.2 85.4 23.2 80.5 21.6 75.8 20.2 73.1 19.5 70.7 18.9 65.8 17.5
5.0 4.1 85.4 22.1 80.5 20.7 75.8 19.4 73.1 18.7 70.7 18.1 65.8 16.8
7.0 6.0 85.4 21.2 80.5 19.9 75.8 18.7 73.1 18.0 70.7 17.4 65.8 16.2
9.0 7.9 85.4 20.4 80.5 19.2 75.8 18.0 73.1 17.4 70.7 16.8 65.8 15.6
11.0 9.8 85.4 19.7 80.5 18.5 75.8 17.3 73.1 16.8 70.7 16.1 65.8 15.1
13.0 11.8 85.4 18.9 80.5 17.8 75.8 16.7 73.1 16.2 70.7 15.6 65.8 14.6
15.0 13.7 85.4 18.3 80.5 17.2 75.8 16.2 73.1 15.6 70.7 15.1 65.8 14.1
19.0 14.2 85.4 17.4 80.5 16.8 75.8 15.7 73.1 14.9 70.7 14.3 65.8 13.5
21.0 15.0 85.4 16.8 80.5 15.9 75.8 15.0 73.1 14.2 70.7 13.6 65.8 12.8
-14.7 -15.0 66.8 26.7 66.8 27.2 64.6 27.6 62.7 26.7 60.7 25.8 56.5 23.8
-12.6 -13.0 70.6 27.2 68.6 27.6 64.8 25.8 62.7 25.0 60.7 24.1 56.5 22.2
-10.5 -11.0 72.8 27.6 68.9 26.1 64.8 24.3 62.7 23.4 60.7 22.5 56.5 20.9
-9.5 -10.0 73.1 27.0 68.9 25.2 64.8 23.6 62.7 22.7 60.7 21.9 56.5 20.2
-8.5 -9.1 73.1 26.3 68.9 24.5 64.8 23.0 62.7 22.1 60.7 21.3 56.5 19.7
-7.0 -7.6 73.1 25.0 68.9 23.4 64.8 21.9 62.7 21.1 60.7 20.4 56.5 18.9
-5.0 -5.6 73.1 23.6 68.9 22.2 64.8 20.7 62.7 20.0 60.7 19.3 56.5 17.9
-3.0 -3.7 73.1 22.5 68.9 21.1 64.8 19.7 62.7 19.1 60.7 18.4 56.5 17.1
0.0 -0.7 73.1 20.9 68.9 19.6 64.8 18.3 62.7 17.7 60.7 17.1 56.5 15.9
3.0 2.2 73.1 19.5 68.9 18.3 64.8 17.2 62.7 16.6 60.7 16.1 56.5 15.0
5.0 4.1 73.1 18.7 68.9 17.6 64.8 16.5 62.7 16.0 60.7 15.5 56.5 14.4
7.0 6.0 73.1 18.0 68.9 17.0 64.8 15.9 62.7 15.4 60.7 14.9 56.5 13.9
9.0 7.9 73.1 17.4 68.9 16.4 64.8 15.4 62.7 14.9 60.7 14.4 56.5 13.4
11.0 9.8 73.1 16.8 68.9 15.8 64.8 14.8 62.7 14.4 60.7 13.9 56.5 13.0
13.0 11.8 73.1 16.2 68.9 15.2 64.8 14.3 62.7 13.9 60.7 13.5 56.5 12.6
80
70
60
355
