68.0KW φ28.58 φ15.88 φ31.8 φ15.88
73.0KW φ31.8 φ19.05 φ38.1 φ19.05
80.0KW φ31.8 φ19.05 φ38.1 φ19.05
85.0 KW φ31.8 φ19.05 φ38.1 φ19.05
90.0 KW φ31.8 φ19.05 φ38.1 φ19.05
96.0 KW φ31.8 φ19.05 φ38.1 φ19.05
101.0KW φ38.1 φ19.05 φ38.1 φ22.22
106.5KW φ38.1 φ19.05 φ38.1 φ22.2
113.0KW φ38.1 φ19.05 φ38.1 φ22.2
118.0KW φ38.1 φ19.05 φ38.1 φ22.2
123.5KW φ38.1 φ19.05 φ38.1 φ22.2
130.0 KW φ38.1 φ19.05 φ38.1 φ22.2
135.0KW φ38.1 φ19.05 φ38.1 φ22.2
Note: When the distance from outdoor to the longest indoor is over 90m, the main pipe
diameter should be enlarged.
d. Pipe “d” diameter (between gather pipes)
Total outdoor capacity
before the gather pipe
Liquid pipe (a, c) Gas pipe (b, d)
~68.0KW φ15.88 φ28.58
69～90.0KW
φ19.05 Φ31.8
e. Pipe “e” diameter (between outdoor and the gather pipe)
outdoor capacity Gas pipe Liquid pipe Oil equalization pipe
8HP φ19.05
10HP φ22.2
φ9.52
12, 14 HP φ25.4 φ12.7
16HP φ28.58 φ12.7
φ9.52
Copper pipe selection:
hardness softness Half-hardness
Outer
diameter
φ6.35 φ9.52 φ12.7 φ15.88 φ19.05 φ22.2 φ25.4 φ28.58 φ31.8 φ34.9 φ38.1 φ41.3
Min.
thickness
0.8 0.8 1.0 1.0 1.0 1.1 1.2 1.4 1.4 1.4 1.4 1.43
Note: If the copper pipe with outer diameter φ19.05 is coil pipe, the thickness should be
over 1.1.
402
