Do not use the fan to handle the air with the following content:

- viscous contaminants prone to deposition in the fan,

- corrosive contaminants which may degrade the fan,

- ammable contaminants, including gas, vapours, mists or particulates which may form explosive mixtures

with air.

•

The control system must prevent extremely frequent power cycling.

Transport and storage

•

Keep the fans in their original packaging in a dry, sheltered room.

•

• Dispose of the fan at the end of its operating life strictly in accordance with environmental protection and

waste management laws.

•

Should it occur, damage caused by improper transport, handling, storage or commissioning will be

demonstrated and is not on warranty.

ACCESSORIES

Available optional accessories:

Terminal block (standard version, no part index sux). Connect the fan equipped with the terminal block

as shown in the electrical wiring diagram, see Fig. 2.

The central fan is started and stopped by a separate on/o switch installed in the power supply line of the

•

Precise where the fan will be installed.

•

Prepare the power cord. Use NYM-O 5x1.5 mm² (H07V-K 5x1.5 mm²).

NOTE: Make sure that the power cord is not live before starting work.

•

Measure and drill the mounting holes in the fan base (6).

•

Measure and drill holes for the mounting studs in the substructure to which the fan will be xed.

•

Fix the fan to the substructure using the mounting holes.

•

Remove the outer insulation from the power cable and remove the 4 mm of insulation from the wires.

•

Route the power cord and connect it to the terminal block according to the wiring diagram in Figure 2.

- The power cable must be sealed to prevent ingress of water into the air exhaust fan along the power cable.

•

Verify the tightness of the wires in the terminals.

•

Secure the cable against slipping out by tightening the nut (5).

•
