English
OVERVIEW
USING THE MODEL M
SELECTING THE AUDIO SOURCE
The audio source can either be selected with the
touch key M or the remote control keys FM, DAB,
and .
FM RADIO
1. Press the FM key on the remote control.
2. Select a FM station with
and
:
• Use a single touch: change frequency by 0.1 MHz.
• Hold down for a short time: automatically search
for another station.
Storing a radio station with the presets
1. Select your favorite radio station using the
or
keys on the remote control or on the touch panel.
2. Select one of the 6 preset keys on the remote
control, and keep pressing it until the correspond-
ing letter on the display starts blinking. The station
has now been stored.
Using the presets
Press one of the preset keys to recall a radio station.
DAB / DAB+ ( MODEL M DAB+ ONLY )
1. Press the DAB key on the remote control.
2. Select a DAB station with
and
.
Model M DAB+ is compatible with DAB and DAB+.
Scan function
When using your Model M for the rst time, the radio
needs to nd available radio stations in your region
( done by using the “Scan” function ). After a scan, the
stations will be automatically stored.
• Within 5 seconds of entering DAB mode, hold down
the
button until “Scan” displays.
“Scan” is also needed after traveling to a new location
with different radio stations, or when you move
the radio to a different room where there is different
radio reception.
BLUETOOTH
Mobile phones and computers with Bluetooth can
connect to the Model M to play music. The mobile
phone or computer must support Bluetooth A2DP.
Initial Setup ( “Pairing” ) With iPhone
®
1. Press the key on the remote control.
2. Select “Settings” on your iPhone
®
. Select “General
/ Bluetooth”. Turn on Bluetooth. New Bluetooth
devices are detected automatically. After a few
seconds “GENEVA M ( Not Paired )” will appear.
3. Select “GENEVA M”. The phone is now connecting
to the Model M ( display shows “C” or “Connect ” ).
4. If the phone asks for a PIN: enter “0000”( four zeros ).
5. Now you can play music on an iPhone
®
and listen
to it on the Model M.
Playing Music
Most phones connect automatically to the Model M
after the initial setup ( “Pairing” ).
1. Press the
key on the remote control.
2. Play music on the mobile phone, music will start
playing on Model M automatically.
Pairing guides for other devices and mobile phones
Go to www.genevalab.com and select “Support.”
Status information on the display
S / Search: Searching previously paired devices.
C / Connect: Successful connection.
P / Pairing: If Model M did not make a successful
connection within 20 seconds, Model M will go into
the pairing mode for 2 minutes.
LINE - IN
1. Connect one end of a Line - In cable to the Line - In
plug on the back of Model M. Then connect the
other end to the audio device ( headphone or Line-
Out plug ).
2. Press the
key on the remote control.
ALARM
Setting the alarm
1. Touch
, “A” starts blinking on the display.
2. Set the desired alarm time using
and
.
3. Touch
again to save the alarm time. “A” indi-
cates alarm is now on.
4. Touch
to turn Model M off.
Turning the alarm On and Off
1. Turn on Model M, then touch
to toggle the
alarm. “A” ( Model M ) or “ON” ( Model M DAB+ )
indicates that the alarm is on.
2. If the device is off, the alarm can also be toggled by
touching any key on the touch panel.
Muting the alarm
Touch any key on the touch panel to mute the alarm.
The alarm will automatically turn off after 2 minutes if
no key on the touch panel is touched.
Selecting the alarm sound
There are two alarm sounds: radio and a beeping
sound. If you set the alarm and the current mode is
FM or DAB, the FM or DAB radio will play when the
alarm goes off. Otherwise the beeping sound is used.
Setting the clock manually
1. Touch
: “C” starts blinking on the display.
2. Use
and to set the time.
3. Touch
to complete the procedure.
Model M DAB+ sets the time automatically.
Every time Model M DAB+ gets a valid time signal from
a DAB station, it will set the time automatically. If there
are no DAB stations, the time has to be set manually.
Model M ( US Version ): AM / PM Display
The dot to the right of the minute digits indicates AM
or PM: Off = AM, On = PM.
AUDIO SOURCES
You can play music from the following audio sources:
• FM Radio
• DAB Radio ( available only for Model M DAB+ )
• Mobile phone or computer via Bluetooth
• Other devices with a Line-In cable
Bluetooth
DAB Radio
FM Radio
Line-In
GETTING STARTED
1. Remove the protection paper from the remote
control battery compartment.
2. Connect the enclosed external telescopic antenna.
Connect the AC power cable to the AC power plug
on the back panel.
REMOTE CONTROL
TOUCH KEYS
Power On / Off
Volume control
Bass control
Treble control
Bluetooth
FM
DAB / DAB+
1
Set time
Set alarm time
Alarm On / Off
Line - In
DAB & FM frequency, alarm
Mute, Mono / Stereo ( FM )
DAB / FM presets
Power On / Off
Volume +
Volume -
Mode: select FM, DAB / DAB+
1
, Line-In or Bluetooth
Change FM / DAB frequency and alarm
Change FM / DAB frequency and alarm
1
DAB / DAB+ is only available for Model M DAB+
