Panasonic WH-UD09CE5-A [134/146] Heating capacity table

134

19.2. Heating Capacity Table

19.2.1. WH-SDF07C3E5 WH-UD07CE5-A

19.2.2. WH-SDF09C3E5 WH-UD09CE5-A

19.2.3. WH-SDF12C6E5 WH-UD12CE5-A

LWC303540455055

Tamb HC IP HC IP HC IP HC IP HC IP HC IP

-15 4.60 1.87 4.60 2.00 4.60 2.19 4.60 2.42 4.55 2.68 4.50 3.00

-7 5.15 1.80 5.15 1.94 5.08 2.14 5.00 2.38 4.90 2.47 4.80 2.67

2 6.70 1.83 6.55 1.98 6.58 2.29 6.60 2.64 6.30 2.90 6.00 3.16

7 7.00 1.43 7.00 1.59 7.00 1.77 7.00 2.12 6.90 2.30 6.80 2.72

25 7.00 0.79 7.00 0.93 6.40 1.03 6.10 1.17 5.90 1.33 5.70 1.49

HC: Heating Capacity (kW)

IP: Power Input (kW)

LWC: Leaving Water Condenser Temperature (°C)

Tamb: Ambient Temperature (°C)

LWC303540455055

Tamb HC IP HC IP HC IP HC IP HC IP HC IP

-15 6.00 2.55 5.90 2.68 5.50 2.82 5.40 3.00 5.20 3.14 5.00 3.33

-7 6.10 2.16 5.90 2.36 5.85 2.63 5.80 2.90 5.80 3.06 5.80 3.22

2 6.80 1.87 6.70 2.16 6.70 2.38 6.60 2.64 6.30 2.90 6.00 3.16

7 9.00 1.93 9.00 2.20 9.00 2.45 9.00 2.81 8.95 3.23 8.90 3.87

25 9.00 1.07 9.00 1.27 8.40 1.40 8.00 1.59 7.80 1.81 7.50 2.03

HC: Heating Capacity (kW)

IP: Power Input (kW)

LWC: Leaving Water Condenser Temperature (°C)

Tamb: Ambient Temperature (°C)

LWC303540455055

Tamb HC IP HC IP HC IP HC IP HC IP HC IP

-15 9.30 3.50 8.90 3.66 8.50 3.83 8.10 3.99 7.50 4.09 7.00 4.20

-7 10.40 3.41 10.00 3.70 9.60 3.99 9.20 4.28 8.70 4.30 8.20 4.31

2 11.80 3.14 11.40 3.35 11.00 3.57 10.60 3.78 9.80 3.98 9.10 4.18

7 12.00 2.14 12.00 2.57 12.00 3.00 12.00 3.43 12.00 3.82 12.00 4.20

25 12.00 1.42 12.00 1.70 11.80 1.98 11.70 2.27 11.50 2.53 11.40 2.78

HC: Heating Capacity (kW)

IP: Power Input (kW)

LWC: Leaving Water Condenser Temperature (°C)

Tamb: Ambient Temperature (°C)
