2 Specifications
2.1. WH-SDF07C3E5 WH-UD07CE5-A
Item Unit Outdoor Unit
Performance Test Condition EUROVENT
Heating Capacity kW 7.00
BTU/h 23900
kJ/h 25200
COP W/W 4.40
BTU/hW 15.0
Noise Level dB (A) 48
Power Level dB 66
Air Flow
m
3
/min (ft
3
/min)
46.0 (1624)
Refrigeration Control Device Expansion Valve
Refrigeration Oil
cm
3
FV50S (900)
Refrigerant (R410A) kg (oz) 1.45 (51.2)
Dimension Height mm (inch) 795 (31-5/16)
Width mm (inch) 900 (35-7/16)
Depth mm (inch) 320 (12-19/32)
Net Weight kg (lbs) 66 (146)
Pipe Diameter Liquid mm (inch) 6.35 (1/4)
Gas mm (inch) 15.88 (5/8)
Standard Length m (ft) 7 (23.0)
Pipe Length Range m (ft) 3 (9.8) ~ 30 (98.4)
I/D & O/D Height Difference m (ft) 20 (65.6)
Additional Gas Amount g/m (oz/ft) 30 (0.3)
Refrigeration Charge Less m (ft) 10 (32.8)
Compressor Type Hermetic Motor
Motor Type Brushless (4-poles)
Rated Output kW 1.70
Fan Type Propeller Fan
Material PP
Motor Type Induction (8-poles)
Input Power W —
Output Power W 60
Fan Speed rpm 580
Heat Exchanger Fin material Aluminium (Pre Coat)
Fin Type Corrugated Fin
Row × Stage × FPI 2 × 30 × 17
Size (W × H × L) mm 38.1 × 762 × 873.8 : 903.8
Item Unit
Power Source (Phase, Voltage, Cycle) ø Single
V 230
Hz 50
Input Power kW 1.59
Maximum Input Power For Heat Pump System kW 4.59
Maximum Input Power For Internal Heater
(Internal Heater + Tank Heater)
kW 3.00 (6.00)
Starting Current A 7.30
Running Current A 7.30
Maximum Current For Heat Pump System A 21.0
Maximum Current For Internal Heater
(Internal Heater + Tank Heater)
A 13.0 (26.0)
