13.8. Indication Panel

Note:

• If Operation LED is blinking, there is an abnormality operation occurs.

13.9. Indoor Back-Up Heater Control

13.9.1. Indoor Electric Heater control

1. Normal Heating Mode

• Heater On condition:

a. Heater switch is ON

b. After Heatpump thermo ON for [30] mins

c. After water pump operate [9] mins

d. Outdoor air temperature < Outdoor set temperature for heater

e. When water outlet temperature < Water set temperature + [-8°C]

f. [20] minutes since previous Backup heater Off

* When heatpump cannot operate due to error happens during normal operation, heater will go into force mode

automatic

* Heater need to operate during deice operation

• Heater Stop Condition:

a. When outdoor set temperature > outdoor set temperature + [+2°C] for continuous 15 secs OR

b. When water out temp> water set temperature + [-2°C] for continuous 15 secs OR

c. Heater switch is Off OR

d. Heat pump thermo-off or OFF condition

2. Force Heater Mode

• Heater On Condition:

a. After water pump operate [9] mins

b. When water outlet temperature < water set temperature + [-8°C]

c. [20] minutes since previous Backup heater Off

• Heater Stop condition

a. Force mode off OR

b. When water outlet temperature > water set temperature + [-2°C] for continuous 15 secs

* Do not operate heater at the following situation

1. Water outlet temperature sensor, and water inlet sensor abnormal

2. Flow switch abnormal

3. Circulation pump stop condition

4. During Heat pump switch to tank side

LED Operation

Color Green

Light ON Operation ON

Light OFF Operation OFF
