141
<Model: WH-UD07CE5-A WH-UD09CE5-A>
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
• “O” marked parts are recommended to be kept in stock.
REF. NO. DESCRIPTION & NAME QTY. WH-UD07CE5-A WH-UD09CE5-A REMARKS
1 BASE PAN ASS’Y 1 CWD52K1199 ←
2 COMPRESSOR DC 280V 1 5KD240XCC21 ← O
3 BUSHING-COMPRESSOR MOUNT 3 CWH50055 ←
4 NUT FOR COMP. MOUNT. 3 CWH561049 ←
4a PACKING 3 CWB811017 ←
6 CONDENSER COMPLETE 1 CWB32C2846 ←
7 CRANKCASE HEATER (COMPRESSOR) 1 CWA341043 ←
8 DISCHARGE MUFFLER 1 CWB121013 ←
10 3-WAYS VALVE (GAS) 1 CWB011251 ←
11 4-WAYS VALVE 1 CWB001026J ←
12 2-WAYS VALVE (LIQUID) 1 CWB021330 ←
20 SOUND PROOF MATERIAL-COMP. 1 CWG302245 ←
21 SOUND PROOF MATERIAL 1 CWG302246 ←
22 SOUND PROOF BOARD ASS’Y 1 CWH151195 ←
23 V-COIL COMPLETE FOR 4-WAYS VALVE 1 CWA43C2169J ← O
24 V-COIL COMPLETE FOR EXP. VALVE 1 CWA43C2342 ← O
25 SENSOR COMP. (OUTLET & COND. THERMISTOR) 1 CWA50C2652 ←
26 SENSOR COMP. (DISCHARGE THERMISTOR) 1 CWA50C2528 ←
27 SENSOR COMP. (TANK THERMISTOR) 1 CWA50C2665 ←
28 CABINET REAR PLATE CO. 1 CWE02C1058 ←
29 CONTROL BOARD ASS’Y 1 CWH10K1100 ←
32 TERMINAL BOARD ASS’Y 1 CWA28K1198 ←
34 ELECTRONIC CONTROLLER (CAPACITOR) 1 CWA746184 ← O
38 ELECTRONIC CONTROLLER (NOISE FILTER) 1 CWA745745 ← O
44 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C4833R CWA73C4834R O
46 REACTOR 2 G0C592J00003 ←
48 TERMINAL COVER 1 CWH171039A ←
49 NUT FOR TERMINAL COVER 1 CWH7080300J ←
50 BRACKET FAN MOTOR 1 CWD54K1052 ←
50a SCREW - BRACKET FAN MOTOR 2 CWH551040J ←
54 FAN MOTOR 1 EHDS80C60AC ← O
54a SCREW-FAN MOTOR 4 CWH551016J ←
55 PROPELLER FAN 1 CWH00K1006 ←
56 NUT - PROPELLER FAN 1 CWH561051 ←
57 CABINET FRONT PLATE 1 CWE061118A ←
58 DISCHARGE GRILLE 1 CWE201073 ←
59 CABINET SIDE PLATE 1 CWE04K1019A ←
60 WIRE NET 1 CWD041102A ←
61 CABINET TOP PLATE CO. 1 CWE03C1053 ←
66 CABINET FRONT PLATE CO. 1 CWE06C1245 ←
67 HANDLE 3 CWE161008 ←
68 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1511 ←
70 EXPANSION VALVE 1 CWB051029 ←
71 PRESSURE SWITCH 1 CWA101013 ←
72 ELECTRO MAGNETIC SWITCH 1 CWA001023 ←
76 PIPE COVER (FRONT) 1 CWD601074A ←
77 PIPE COVER (BACK) 1 CWD601075A ←
78 STRAINER 2 CWB111024 ←
80 HIGH PRESSURE SENSOR 1 CWA50C2570 ←
81
ACCESSORY-COMPLETE 1 CWH82C1535 ←
