Panasonic CS-F50DD1E5 / CU-B50DBE8 [122/147] Cs f34dd1e5 cu b34dbe5

13.4.2.4. CS-F34DD1E5 CU-B34DBE5

Model Heating capacities are based on conditions

CS-F34DD1E5 CU-B34DBE5 Single phase, 50Hz, 230V

Heating capacity Indoor temp. 20°C D.B.

11.2 kW Outdoor temp. 7°C D.B. 6°C W.B.

Standard air volume 40 m

/min

TC : Cooling Capacity

SHC : Sensible Heat Capacity

IPT : Cooling Power Consumption
